11

7. Locking ring
8. Cable storage hooks
9. Motor housing

10. Pedal (GL670/GL670P)
11. Guard
12. Line trimming blade
13. Edge guide
14. Spool housing
15. Cutting line

ASSEMBLY

Before assembly, make sure that the tool
is switched off and unplugged.

Fitting the guard (fig. B)

◆

Unplug the tool.

◆

Remove the screw (16) from the housing.

◆

Place the guard (11) onto the tool as shown.

◆

Firmly press the guard until it snaps into place.

◆

Secure the guard with the screw (16).

Never use the tool unless the guard is
properly fitted.

Releasing the cutting line (fig. A)

In transit, the cutting line is taped to the spool
housing.

◆

Remove the tape holding the cutting line (15)
to the spool housing (14).

Fitting the plant protector (fig. C)

The plant protector is supplied as a standard
accessory with the GL660P & GL670P. For other
models, it is available as an optional accessory.

◆

Place the plant protector (17) over the guard as
shown. Make sure that the orientation is correct.

◆

Place the two plastic caps (18) onto the plant
protector, aligning any of the marks (19) on the
caps with those on the guard (11).

◆

Secure the caps using the screws (20). Do not
overtighten the screws.

Wait until the cutting line has come to a
standstill before adjusting the plant
protector.

E N G L I S H

◆

The cable wire colours, or a letter, will be
marked at the connection points of most good
quality plugs. Attach the wires to their
respective points in the plug (see above).
Brown is for Live (L) (2), blue is for Neutral (N) (4).

◆

Before replacing the top cover of the mains
plug ensure that the cable restraint (3) is
holding the outer sheath of the cable firmly
and that the leads are correctly fixed at the
terminal screws.

◆

If the plug has a fuse cover, make sure that the
fuse cover is fitted. Do not use the plug if the
fuse cover is missing or damaged.

Never use a light socket.

Using an extension cable

Always use an approved extension cable suitable
for the power input of this appliance (see rating
plate). The extension cable must be suitable for
outdoor use.

◆

Before use, inspect the cable for signs of
damage, wear and ageing. Replace the
extension cable if damaged or defective.

◆

When using a cable reel, always unwind the
cable completely.

◆

Take care to keep the cable away from the
cutting line. Always be aware of the position of
the cable.

CARTON CONTENTS

The carton contains:

1 Grass trimmer
1 Guard with mounting screw
1 Plant protector incl. parts pack

(GL660P/GL670P only)

1 Instruction manual

◆

Carefully unpack all parts.

OVERVIEW (fig. A)

1. On/off switch
2. Handle
3. Cable restraint
4. Power inlet (not for UK)
5. Secondary handle
6. Handle button (GL670/GL670P)
