18
GB
440 488 _a
2.
Remove flange (3) and cutting blade (2).
3. Place new cutting blade (2) on driver plate (1) so that
the hole in the cutting blade precisely aligns with the
guide circle in the driver plate.
4.
Push flange (3) onto the cutting blade so that the flat
side points towards the cutting blade.
5. Loosely screw fastening nut (4) anticlockwise onto the
guide pin of drive shaft (1).
6. Brace driver plate (1) using an Allen key and tighten
fastening nut (4) anticlockwise with hex key (5).
7. Secure the fastening nut with the split pin again.
Changing the spool
(Fig. 7)
1. Brace driver plate (2) using Allen key (1) and loosen
fastening screw (4) clockwise with spanner (5).
2. Unscrew and remove fastening screw.
3. Pull spool head (3) off the drive shaft.
4. Remove the spool from the spool head.
5. Remove dirt and grass residues.
6. Thread the ends of the cutting lines from the new
spool into the openings provided for them in the spool
head.
7. Insert the spool into the spool head. Make sure that
the cutting lines do not become jammed, and pull
them out of the spool by about 9 cm.
8. Push the complete spool head onto the drive shaft
and tighten anticlockwise with the fastening screw.
9. Hold the driver plate
firmly and tighten with the
spanner.
IMPORTANT!
Only use genuine cutting blades and accessories!
Non-genuine parts can lead to injuries and
malfunctions of the machine!
Changing the line knife
1. Unscrew and remove the two screws arranged on the
inside edge of the guard plate and remove the old
line knife.
2. Insert the new line knife and screw it back on. Do not
overtighten the screws.
Sharpening the line knife
1. Remove the cutting blade from the guard plate.
2. Secure the line knife in a vice and sharpen it with a
flat file. Only file in one direction!
Cleaning
Clean the machine carefully after each use in
order to keep it functioning correctly.
Regularly clean all moving parts.
Clean the housing with a soft brush or a dry cloth.
Do not clean the machine with running water or high-
pressure washers.
Do not use solvents (petrol, alcohol, etc.) for the plastic
parts, since these can damage the plastic parts.
Keep the handle grips free from oil and grease. Water,
solvents and polishes are not allowed to be used.
Storage
Clean the machine and its accessories after each use.
Store the machine in a dry place protected against
frost.
Hang up the electric brushcutter by its handle.
This avoids placing unnecessary load on the
cutter head.
Disposal
Do not dispose of worn-out
machines in domestic waste!
The packaging, machine and accessories are made
from recyclable materials and must be disposed of
accordingly.
Technical data
Technical data acc. to the following standards:
Mechanical safety acc. to EN 786, 5.1.1, Annex
E and D,
sound pressure and sound energy level acc. to DIN EN
ISO 3744:2010,
measurement of mechanical vibration at the hand grip
acc. to EN 28662-1:1992.
