5

BP A200 Afib

EN



Sometimes the device will detect atrial fibrillation even when

it is not there. This can happen if the arm moves during the

reading or another rhythm problem is present. Keep the arm

still during the reading. Visiting your doctor with this device

may be necessary to check out any rhythm problems.



This device may not detect atrial fibrillation in people with

pacemakers or defibrillators.

6. PC-Link Functions

This device can be used in conjunction with a personal computer

(PC) running the Microlife Blood Pressure Analyser (BPA) software.

The memory data can be transferred to the PC by connecting the

monitor via a cable.

If no CD and cable is included download the BPA software from

www.microlife.com and use a USB cable with a Mini-B 5 pin

connector.

Installation and data transmission

1. Insert CD into the CD ROM drive of your PC. The installation

will start automatically. If not, please click on «SETUP.EXE».

2. Connect the monitor via the cable to the PC; there is no need to

switch the device on. 3 horizontal bars will appear on the

display and last for 3 seconds.

3. The bars will then flash to indicate that the connection between

PC and device is successful. As long as the cable is plugged in,

the bars will keep flashing and the buttons are disabled.



During the connection, the device is completely controlled

by the computer. Please refer to the «help» file for software

instructions.

7. Data Memory

At the end of each measurement, this device automatically stores

the result, including date and time.

Viewing the stored values

Press the M-button

2

 briefly, when the device is switched off. The

display first shows «

M

»

AS

 and then a value, e.g. «

M 17

». This

means that there are 17 values in the memory. The device then

switches to the last stored result.

Pressing the M-button again displays the previous value. Pressing

the M-button repeatedly enables you to move from one stored

value to another.

Memory full



Pay attention that the maximum memory capacity of 200 is

not exceeded.

When the memory is full, the old values

are automatically overwritten with new ones.

 Values

should be evaluated by a doctor before the memory

capacity is reached – otherwise data will be lost.

Clearing all values

If you are sure that you want to permanently remove all stored

values, hold down the M-button (the device must have been

switched off beforehand) until «

CL

» appears and then release the

button. To permanently clear the memory, press the M-button

while «

CL

» is flashing. Individual values cannot be cleared.

8. Battery Indicator and Battery change

Low battery

When the batteries are approximately ¾ empty the battery symbol

AR

will flash as soon as the device is switched on (partly filled battery

displayed). Although the device will continue to measure reliably, you

should obtain replacement batteries.

Flat battery – replacement

When the batteries are flat, the battery symbol

AR

 will flash as soon

as the device is switched on (flat battery displayed). You cannot

take any further measurements and must replace the batteries.

1. Open the battery compartment

AT

 at the back of the device.

2. Replace the batteries – ensure correct polarity as shown by the

symbols in the compartment.

3. To set date and time, follow the procedure described in

«Section 3.».



The memory retains all values although date and time must

be reset – the year number therefore flashes automatically

after the batteries are replaced.

Information for the doctor on frequent appearance of the

atrial fibrillation indicator

This device is an oscillometric blood pressure monitor that also

analyses pulse frequency during measurement. The device is

clinically tested.

The AFIB symbol is displayed after the measurement, if atrial fibril-

lation occur during measurement. If the symbol appears more

frequently (e.g. several times per week on measurements

performed daily) we recommend the patient to seek medical advice.

The device does not replace a cardiac examination, but serves

to detect atrial fibrillations at an early stage.
