©2021 TP-Link   7106509115   REV2.5.0

Option1: Standalone Mode

Via Omada App

1.

 Connect wirelessly by using the default SSID (format:

TP-Link_2.4GHz/5GHz_XXXXXX

) printed on the label at the bottom of the

product.

2.

 Launch a web browser and enter

http://tplinkeap.net

 in the address bar. Use

admin

 for both Username and Password to log in.

3.

 Set up a new Username and Password for secure management purpose. Modify

the wireless parameters and reconnect your wireless devices to the new

wireless network.

To configure other EAPs, connect your device to the EAP by the coresponding

default SSID and repeat the steps listed above. You can configure some basic

functions in Standalone Mode. If you want to configure advanced functions, use

Controller Mode.

1.

 Download the TP-Link Omada App on your mobile device. It can be downloaded

from App Store or Google Play:

2.

 Connect your mobile device to the EAP by using the default SSID (format:

TP-Link_2.4GHz/5GHz_XXXXXX

) printed on the label at the bottom of the

product.

3.

 Open the Omada App, and wait for the EAP to appear on the

Standalone APs

page. Tap on the EAP you want to configure.

The Omada App is designed to help you quickly configure the common settings. If

you want to configure advanced settings, log in to the web page of your EAP or

the controller.

Via a Web Browser

Scan for Omada App

Download Omada App

or

The EAP supports two configuring options:

To configure and manage EAPs singly (usually suitable for a small network with a

few EAPs), Standalone Mode is recommended. Please refer to Option 1.

To configure and manage EAPs in batch, Controller Mode is recommended.

Please refer to Option 2.

A DHCP server (typically a router with DHCP function enabled) is required to assign

IP addresses to the EAPs and clients in your local network.

Via Omada Cloud-Based Controller

1.

 Download the TP-Link Omada App on your mobile device. It can be downloaded

from App Store or Google Play:

2.

Launch Omada App and log in with your TP-Link ID. Then go to

Cloud Access

. A

list of controllers

that have been bound with your TP-Link ID will appear. Then

you can further configure the controller.

With Omada App, you can also manage your Omada Cloud-Based Controller.

Scan for Omada App

Download Omada App

or

Omada App

For the detailed configurations, refer to the User Guide of the controller and EAPs. The guides can be

found on the download center of our official website: https://www.tp-link.com/support/download/.

Safety Information

Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
Do not use the device where wireless devices are not allowed.

For technical support, the user guide and other information, please visit

https://www.tp-link.com/support

, or simply scan the QR code.

If you have any suggestions or needs on the product guides, welcome to email

techwriter@tp-link.com.cn

.

To ask questions, find answers, and communicate with TP-Link users or engineers,

please visit

https://community.tp-link.com

to join TP-Link Community.

Option2: Controller Mode

Controller Mode applies to the large scale network with mass devices. All devices can

be centrally configured and monitored via Omada Software Controller, Omada

Hardware Controller or Omada Cloud-Based Controller.

Omada Hardware Controller (OC200/OC300), which is pre-installed with Omada

Software Controller, is a good alternative if you have no spare PC to keep running

Omada Software Controller in the network.

It needs to be purchased additionally.

For

more details, refer to the Installation Guide of OC200/OC300.

Via Omada Software Controller

Via Omada Hardware Controller (OC200/OC300)

1.

 Download the TP-Link Omada App on your mobile device. It can be downloaded

from App Store or Google Play:

With Omada App, you can also manage your Omada Software Controller at a local site

and remote site.

Note that Omada Software Controller needs to be kept running when

using Omada App.

Local Management

Scan for Omada App

Download Omada App

or

2.

 Launch your Omada App and configure the controller at a local site or remote site.

Remote Management

Omada App

a.

Connect your mobile device to the EAP by using the default SSID (format:

TP-Link_2.4GHz/5GHz_XXXXXX

) printed on the label at the bottom of the

product.

b.

L

aunch Omada App and go to

Local Access

, tap the

+

 button on the upper-right

corner to add the controller. Then you can further configure the controller.

a. Make sure

Cloud Access

 is enabled on your controller and your controller has

been bound with your TP-Link ID.

b.

Launch Omada App and log in with your TP-Link ID. Then go to

Cloud Access

. A

list of controllers

that have been bound with your TP-Link ID will appear. Then

you can further configure the controller.

Omada Cloud Portal

1.

 On the PC with Windows OS or Linux OS, download the Omada Software Controller

installation file from

https://www.tp-link.com/support/download/omada-software-controller/

.

2.

 Run the file and follow the wizard to install the Omada Software Controller.

3.

 Launch the Omada Software Controller and follow the step-by-step instructions to

complete the Quick Setup. After the wizard is finished, a login screen will appear.

4.

 Enter the username and password you created and click

Log in

. Then you can

further configure the network.

1

. Enable

Cloud Access

 on the setting page on the controller and

bind a TP-Link ID to

your controller. If you have configured this in the setup wizard, skip the step.

2

. Launch a web browser and ente

r

https://omada.tplinkcloud.com

in the address bar.

3

.

Enter your TP-Link ID and password to log in. A list of controllers that have been

bound with your TP-Link ID will appear. Then you can click

 Launch

 to further

configure the controller.

After installing Omada Software Controller, you can remotely access the controller

through Omada Cloud Portal. Follow the steps below.

Software Configuration

4

Clients

PoE Switch

Router

EAP

EAP

Omada Hardware Controller

(OC200/OC300)

Controller

Omada Software Controller

running on the Management PC

Or

EAP

Internet

Router

EAP

EAP

PoE Switch

Clients

PoE Switch

Router

Clients

EAP

EAP

EAP

Omada Cloud-Based Controller

Before managing the devices via Omada Cloud-Based Controller, make sure they

can access the internet.

1. Launch a web browser and enter https://omada.tplinkcloud.com in the address

bar. Enter your TP-Link ID and password to log in.

2. Click

Add Controller

 and register for an Omada Cloud-Based Controller. Follow

the instructions to complete the setup process.

3. Add devices with the serial number, make sure the devices are online and in

factory default.

4. Assign appropriate licenses in order to manage and configure the devices on

the cloud-based controller. Then wait until your controller is deployed.
