1.     Take out the unit, pull the body cover according to the oppo-

site side of arrow from the left side, after it loose, take off the
cover, turn the small screwdriver counter-clockwise and take
out the battery door, insert one AAA size battery based on the
indicator in battery compartment, then the LCD will be in full
display for 2 seconds, it will start to measure the room temper-
ature. Then the below digit for “Hour” and “Minute” will be in
blink, press “clock set” button to set the current standard time.
After loose the button for 6 seconds, the position for time will
turn to show today highest and lowest temperature.

2.     Put the battery door, and screw it well again (pay more atten-

tion to put waterproof loop in right way, then screw the battery
door). Push the body cover according to the arrow way.

3.     After the unit measures the current temperature, the trend

won’t shown on the LCD at once. When it shows

, it indicates

that the temperature have the trend of increasing. When it
shows

, it indicates that the temperature have the trend of

decreasing. If it is without showing these two indicators, it
means that the data is in stable during the current time.

4.     Please replace the battery when the LCD display becomes

dark in use.

       Wiping  up  the  windows’  part  for  the  sticking  position,  rive  off

one side paper of the transparent glue tape, stick the product
in the windows. Pay more attention to stick firmly in case of
falling off.

        1 main unit, 1 mounting with glue tape, 1 manuals, 1 warranty

coupon, 1 gift box

RST01777, RST01278, RST01288, RST01289, RST01291

20

power on

fixation of unit

contents of the package:
