Connection

Connection

Outdoor Antenna Connection

Use 75

Ω

coaxial cable plug or 300-75

Ω

impedance converter to plug in antenna input
terminal on the rear of the cabinet.

Other connections

•  Connect a video source to the Composite

video input jack with RCA cable (not included).

•  Connect an audio source to the proper

Audio input jacks (left and right).

•  Connect the included DC adapter to the

DC input of this unit.

•  When using the unit as a computer screen,

connect the PC to the VGA jack of the unit by
the relevant cable to get the video signal from
the PC. For audio signal from the PC, connect
the left and right jacks of the VGA/Component
audio input of this unit to the audio output jack
of the PC by using relevant connector (not
included).

•  If the video source has a HDMI output

jack, you can connect the signal to the unit by
HDMI cable (not included).

•  Component input is intended for receiving

component video signal if connected to the
component output of external signal source.

•  Connect an external device (e.g., VCR-/

DVD-recorder) to the proper Audio/Video
output jacks of this unit with AV RCA cable (not
included).

•  Coaxial output is intended for transmitting

multi-channel sound to an external decoder
(e.g. in 5.1-CH format). RCA cable should be
used for connection.

Wall mounting

For wall mounting the back panel of

this unit is equipped with 2 screw holes (4
mm diameter, 100 mm horizontal spread
distance). The accessories also include 2
screws designed for using with whic unit for
wall-mounting. A wall-mount bracket should
be used for wall mounting (the bracket is not
included and should be acquired separately).
Manufacturer is not responsible for improper
mounting resulting in damage of the unit.
