Operation

13

13

Operation

changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Operations of file playback

•  Insert a USB into the USB jack. Select

USB source and press OK button. The screen
will show a USB playback window, in which
you can select Movie, Music, Photo and File
contents to play by pressing LEFT/RIGHT
cursor buttons and OK button.

•  Press cursor buttons to select Return

option and press OK button on the RC if you
want to go back to the previous menu.

•  In the content menu, press cursor buttons

to select folder, press OK button on the RC
to enter it, then press cursor buttons to select
the file you want to watch or to listen to. When
highlighting the file, the file information will
appear and picture will be previewed (not
available for music files). Press PLAY and
PAUSE buttons on the RC to play the selected
file.

•  While playback, press INFO button; the

bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons on the RC or perform
this operation by pressing OK button on the
RC. Some of the operations are as follows:

Play or pause playback

All files

Select previous file

All files

Select next file

All files

Stop plabyack and return to
previous menu

All files

Select repat playback mode

All files

Play music in background
mode when photo or text
file is being browsed (you
should select music file first)

and
Text

Show playlist

All files

Show file information

All files

Rotate image clockwise


Rotate image anti-clockwise


Fast backward playback

Music/
Movie

Fast forward playback

Music/
Movie

Mute the sound

Music/
Movie

Select time to start playback
from

Music/
Movie

Fragment repeat playback.
Press OK to select initial
point, press OK to select
final point of the fregment

Movie

Slow playback

Movie

Step playback

Movie

Zoom in

Movie/

Zoom out

Movie/

•  While playback, press   button to pause

or resume playback. Press   button to stop
playback.

•  When you select a file to play, you can

delete the selected file by pressing Red button,
then OK on the RC.

•  When playing music files you can press

/

 buttons to fast reverse or forward. You can

press

/

 buttons to select the desired files

manually in normal condition.

•  When playing text files, you can press CH+/

CH- buttons to page up or page down the file.
