Operation

10

10

Operation

on the RC or VOL+ button on the panel to
start automatical search of available channels.
Current frequency and and channel number
will be displayed. To stop search, press MENU
button, then LEFT button on the RC.

•

Manual search:

 press RIGHT cursor

button on the RC or VOL+ button on the panel
to enter manual search mode. Press LEFT/
RIGHT cursor buttons on the RC or VOL+/
VOL- buttons on the panel to select the channel
number. Then press DOWN cursor button
to select SEARCH, then again press LEFT/
RIGHT cursor buttons on the RC or VOL+/VOL-
buttons on the panel to start channel search. To
stop search, press MENU button on the RC.

•

Fine tune

: press RIGHT/LEFT cursor

buttons to adjust the frequency.

•

Channel edit

: press RIGHT cursor button

on the RC to enter channel edit mode.

Channel edit

1 CH

4 CH

7 CH

2 CH

5 CH

8 CH

3 CH

6 CH

9 CH

1:Delete

2:Move

3:Skip

OK:Enter

Menu:Exit

•  Delete: select a channel with cursor

buttons. Press “1“ number button to delete
the selected channel. Press MENU button to
confirm and return.

•  Move: select a channel with cursor

buttons. Press “2“ number button, then press
UP/DOWN cursor button to select the new
position for the channel. Press MENU button to
confirm and return.

•  Skip: select a channel with cursor buttons.

Press “3“ number button, to set this channel for
skipping.

USB operation

Insert a USB into the USB jack. Select USB

source and press OK button. The screen
will show a USB playback window, in which
you can select Music, Photo, Movie and Text
contents to play by pressing LEFT/RIGHT
cursor buttons and OK button.

  USB file systems supported: FAT16,

FAT32, NTFS. 2.0 USB version is supported,
maximum capacity is 500 Gb. For correct and
satisfactory operation, licensed USB devices
of famous brands should be used with this
unit. Avoid using USB devices of unknown
brands. Playback of some file formats cannot
be supported.

•  This unit supports playback of video files

with ASF, AVI, MKV, MPG, M2TS, MP4, TS,
extension, with video codecs DIVX, H264,
MPEG-4, MPEGII, MPEGI, XVID and audio
codecs AAC, WMA, MP3.

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning:

usage of external USB drives
