Operation

12

12

Operation

USB operation

General playback information

• Insert a USB drive into the USB port.

Select Media source and press ENTER button.
The screen will show a USB playback window,
in which you can select Music, Photo, Movie
and Text contents to play by pressing LEFT/
RIGHT cursor buttons and ENTER button.

• USB file systems supported: FAT32,

2.0 USB version is supported; maximum
capacity 1 TB. For correct and satisfactory
operation, licensed USB devices of well-known
brands should be used. Avoid using USB
devices of unknown brands. Playback of some
file formats cannot be supported.

• This unit supports playback of video files

with ASF, AVI, MKV, MPG extensions, with
video codecs WMV9, DIVX, H263, MPEG-4,
MPEGII, XVID and audio codec MP3.

The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs should be read by this unit.

• Some AVI files cannot be played due to

their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warranty cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Operations of file playback

• Insert a USB into the USB port. Press the

SOURCE button or select USB source and
press ENTER button on the RC or VOL+ on
the unit. The screen will show a USB playback
window, in which you can select Music, Photo,
Movie and Text contents to play by pressing
LEFT/RIGHT cursor buttons and ENTER
button.

• In the content menu, press cursor buttons

to select folder, press ENTER button or
button to enter it, then press cursor buttons to
select the file you want to watch or to listen to.
When highlighting the file, the file information
will appear on the right (not available for text
files) and picture will be previewed in the center
(not available for music and text files). Press
ENTER button or   button to play the selected
file.

• While playback, press ENTER button; the

bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons or perform this operation
by pressing ENTER button.

• While playback, press   button to pause

or resume playback. Press   button to stop
playback.

• When playing music files you can press

/

 buttons to fast reverse or forward. You can

press

/

 buttons to select the desired files

manually in normal condition.

• When playing photo files, you can press

/

 buttons to page up or page down the

file. Press LEFT/RIGHT cursor buttons to
rotate the image.

• Press EXIT button to stop playback and

return to the previous menu screen.
 corner, the list of the current available
channels on the left, and the name of each
programme starting in scheduled time periods
on the right. Select the channel by pressing
UP/DOWN and the programme by pressing
LEFT/RIGHT.
