The remote control does not function.

• Replace the batteries.

The parental lock password has been
forgotten.

• Enter 9999 for the PIN and enter the new PIN.

The screen becomes darker while watching
TV.

• If the whole image or part of the image

remains still, the screen brightness will be
gradually reduced to prevent image retention.
This is not a malfunction of the TV.

You are concerned about image retention.

If the same image is displayed repeatedly or for
long periods of time, image retention may
occur. To reduce image retention, we
recommend that you turn off the TV normally by
pressing the power button on the remote
control or the TV.

Note

• Perform Panel refresh only when image retention is

particularly noticeable. Avoid performing Panel
refresh more than once a year because it may affect
the usable life of the panel.

• Images that include clocks, logos and bright colours

(including white) easily cause image retention. Avoid
displaying these types of images for long periods of
time, otherwise image retention may occur.

The message [Panel refresh did not finish…] is
displayed.

When i) the TV is turned on or ii) the mains lead
is unplugged during the Panel refresh, the Panel
refresh is not completed. Please avoid the
above two conditions during the Panel refresh.

Specifications

System

Panel system: OLED (Organic Light Emitting
Diode) Panel
TV system: Depend on your country/area
selection/TV model

Analogue: B/G, D/K, I
Digital: DVB-T/DVB-C/DVB-T2
Satellite: DVB-S/DVB-S2

Colour system: PAL/SECAM/NTSC3.58 (Video
only)/NTSC4.43 (Video only)
Channel coverage: Depend on your country/
area selection/TV model

Analogue: UHF/VHF/Cable
Digital: UHF/VHF/Cable
Satellite: Intermediate Frequency
950-2150 MHz

Sound output

XR-77A8xK: 20 W + 10 W + 10 W + 10 W + 10 W
XR-65A8xK / 55A8xK: 10 W + 10 W + 10 W +
10 W + 10 W

Wireless technology

Protocol IEEE 802.11a/b/g/n/ac
Bluetooth® Version 4.2

Input/Output jacks

Antenna (aerial)/cable

75 ohm external terminal for VHF/UHF

Satellite antenna

Female F Type Connector, 75 ohm.
DiSEqC 1.0, LNB 13 V/18 V & 22 kHz tone, Single
Cable Distribution EN50494.

/

 AV IN / S-CENTER SPEAKER IN

Video/Audio input (mini jack)
S-centre speaker input (mini jack)

HDMI IN 1/2/3/4 (HDCP 2.3-compatible)

Video:

4096 × 2160p (50, 60 Hz)*

1

*

2

, 4096 × 2160p

(24 Hz)*

1

, 3840 × 2160p (50, 60 Hz)*

2

, 3840 ×

2160p (24, 25, 30 Hz), 1080p (30, 50, 60, 100,
120 Hz), 1080/24p, 1080i (50, 60 Hz), 720p
(30, 50, 60 Hz), 720/24p, 576p, 480p, PC
Formats*

3

3840 × 2160p (100, 120 Hz)*

2

*

4

Audio:

In eARC (Enhanced Audio Return Channel)
mode

Refer to the online Help Guide for details.

Except eARC mode

5.1 channel linear PCM: 32/44.1/48/88.2/
96/176.4/192 kHz 16/20/24 bits, Dolby
Audio, Dolby Atmos, DTS

eARC/ARC (Enhanced Audio Return Channel/
Audio Return Channel) (HDMI IN 3 only)*

5

In eARC mode

Refer to the online Help Guide for details.

In ARC mode

Two channel linear PCM: 48 kHz 16 bits,
Dolby Audio, Dolby Atmos, DTS

DIGITAL AUDIO OUT (OPTICAL)

Digital optical jack (Two channel linear PCM:
48 kHz 16 bits, Dolby Audio, DTS)

For more information on
troubleshooting, refer to the Help
Guide.
Press

 (Input select) on the

remote control and select [Help]. If
[Help] does not exist, select [Edit]
and add [Help].
