7

GB

GB

Power, Product Fiche and others

Power requirements

220 V - 240 V AC, 50 Hz

Energy Efficiency Class*

6

XR-85X9xK: B
XR-75X9xK: B

Screen size (measured diagonally) (Approx.)

XR-85X9xK: 214.8 cm / 85 inches
XR-75X9xK: 189.3 cm / 75 inches

Power consumption*

6

In [Standard] mode

XR-85X9xK: 296 W
XR-75X9xK: 244 W

Annual energy consumption*

6

*

7

XR-85X9xK: 411 kWh per year
XR-75X9xK: 338 kWh per year

Standby power consumption*

6

*

8

*

9

XR-85X9xK: 0.50 W (30 W in software/
EPG update mode)
XR-75X9xK: 0.50 W (33 W in software/
EPG update mode)

Display resolution (horizontal × vertical) (pixels)

3840 × 2160

Output rating

500 mA (for USB 1), 900 mA (for USB 2)

Dimensions (Approx.) (w × h × d) (cm)

with Table‐Top Stand

Standard position:
XR-85X9xK: 188.9 × 109.7 × 45.0
XR-75X9xK: 166.7 × 97.2 × 39.1
Narrow position:
XR-85X9xK: 188.9 × 111.0 × 45.0
XR-75X9xK: 166.7 × 98.4 × 39.1
Soundbar position:
XR-85X9xK: 188.9 × 115.8 × 45.0
XR-75X9xK: 166.7 × 103.3 × 39.1

without Table-Top Stand

XR-85X9xK: 188.9 × 108.6 × 5.6
XR-75X9xK: 166.7 × 96.1 × 5.6

Stand width (Approx.) (cm)

Standard position:

XR-85X9xK: 188.8
XR-75X9xK: 166.5

Narrow position:

XR-85X9xK: 75.8
XR-75X9xK: 57.1

Soundbar position:

XR-85X9xK: 188.8
XR-75X9xK: 166.5

Mass (Approx.) (kg)

with Table-Top Stand

XR-85X9xK: 54.7
XR-75X9xK: 44.1

without Table-Top Stand

XR-85X9xK: 53.2
XR-75X9xK: 42.7

Others

Optional accessories

Wall-Mount Bracket: SU-WL450
Camera and Microphone Unit: CMU-BC1

Operating temperature: 0 ºC – 40 ºC
Operating humidity: 10 % – 80 % RH (non-
condensing)

*1

When 4096 × 2160p is input and [Wide mode] is set
to [Normal], the resolution is displayed as 3840 ×
2160p. To display 4096 × 2160p, set [Wide mode]
setting to [Full 1] or [Full 2].

*2 Refer to the on screen menu to set [HDMI signal

format].

*3 Refer to the online Help Guide for details.
*4 HDMI IN 3 & 4 only. Use the Ultra High Speed HDMI

Cable to connect.

*5 Connect your audio system to the HDMI IN 3 to

route TV audio to your audio system.

*6 This information is for EU and other countries

whose relevant regulation is based on EU energy
labelling regulation.

*7 Energy consumption in kWh per year, based on the

power consumption of the television operating
4 hours per day for 365 days. The actual energy
consumption will depend on how the television is
used.

*8 Specified standby power is reached after the TV

finishes necessary internal processes.

*9 Standby power consumption will increase when

your TV is connected to the network.

Note

• Optional accessories availability depends on

countries/region/TV model/stock.

• Design and specifications are subject to change

without notice.

• Subscriptions for services and applications may be

required and additional terms, conditions and/or
charges may apply when using Google Assistant.

Notes on Digital TV function

• Digital TV (DVB terrestrial, satellite and cable),

interactive services and network functions
may not be available in all countries or areas.
Some functions might not be enabled or
might not operate correctly with some
providers and network environments. Some
TV service providers may charge a fee for their
services.

• This TV supports digital broadcasting using

MPEG-2, H.264/MPEG-4 AVC and H.265/HEVC
codecs, but compatibility with all operator/
service signals, which may change over time,
cannot be guaranteed.
