EN



What is included in the box

Supply of this TV includes following parts:

• 1x

TV

• 1x

RF

cable

•

1x Remote control

•

1x TV stand installation packet
& screw set for wallmount

•

2x AAA batteries

•

1x User guide

•

1x Mini Component adapter
cable

•

1x Mini Composite adapter
cable

•

1x Mini SCART adapter cable



Attaching the Stand

Please follow the instructions on last page of this user manual.



Getting started - initial set up

1.

Insert the batteries supplied into the Remote control.

2.

Using the RF cable supplied, connect the TV to the TV Aerial wall
socket.

3.

For connecting to the Internet with a wired connection connect a
Cat 5/Ethernet cable (not included) from the TV to your broadband
modem/router.

4.

Connect the power cable to the Electrical outlet. You will be now
welcomed with the

First Time Installation

 screen.

5.

If it does not appear, press and hold TV control stick on TV back cover until
special menu appears. Choose option Pair Again.

Please press and hold

the blue and yellow buttons for a few seconds on the remote control,
until white LED on TV front blinked fi ve times.

 Press [MENU] then 8-8-

8-8 and the First Time Installation screen will appear.

6.

If you wish to make changes to any of the default settings, use the
scroll

▲/▼/◄/►

 buttons. To exit this menu at anytime, press [EXIT ]

button.

7.  Please set desired settings in INSTALLATION GUIDE.

STEP 1 -

 Set the TV Menu language.

STEP 2 -

 Set type of network connection. If you wish to skip this step

and connect TV to network later, please choose

Skip Network Setting

STEP 3 -

Select the location of TV. For home use, please select Home.

For shop demonstration mode, set Store.

STEP 4 -

 Choose Digital TV tuning options:

DVB Antenna -

 You can choose between Terrestrial (DVB-T ), Cable

(DVB-C) or Satellite (DVB-S).

Tunning Mode -

 Choose if you want to tune only Digital (DTV )

Analogue (ATV ) or both Digital and Analogue (DTV + ATV )

Country -

 Set the desired country.

Operator -

Select Cable provider. If your cable operator is not listed

select Others. (Avaliable only if DVB Antenna is set to CABLE)

8.  Press [Auto Tuning] button to start the tuning process.

9.  Optional channel presets DVB-C:

Keep all default settings as  recommended.

If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform a new search. Press the [MENU], select
"Network ID" and enter the network ID.

10.  Optional channel presets DVB-S2*:

 Select "Satellite" in the "DVB

Antenna" in the menu for the optional channel presets. Here you can
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported

into your TV system.

Confi rm with [OK] button on the remote control, to start scanning.

TIP:

If you are missing channels, the reason for this is likely to be signal

strength, you should consider connecting signal booster and re-tuning the TV.

* - Available only for TVs with DVB-S tuner



Remote control

Radio controlled remote control - No more aiming in the TV direction!
Refer to remote control picture on the second page of this user
manual.

1.

 STANDBY –

 Switch on TV when in standby or vice versa.

2. NET+

–

 Displays AQUOS NET+ menu.

3.

 MUTE –

Mute the sound or vice versa.

4.  0 – 9 –

to select a TV channel directly.

5. YouTube

–

 Displays YouTube application.

6. SMART

–

 Displays SMART MEDIA menu.

7. SOURCE

–

To display the input/source menu.

8.  TV GUIDE –

Opens the 7 Day TV Guide (Digital mode).

9.

 –

 To return to the previous channel viewed.

10. DTV –

 Switch to digital TV source.

11. VOL

▲/▼

 –

 To increase / decrease the sound level.

12. FAV –

 To display favourites menu.

13. INFO –

Press once for now/next channel information. Press twice for

programme information about current programme.

14. CH

 ▲/▼

 –

To increase or decrease the channel being watched.

15. SUBTITLE –

To switch the dialogue at the bottom of the screen (on/

off ).

16. TELETEXT –

Teletext mode - To enter Teletext

17. MENU –

 To display OSD menu.

18. BACK –

 Back to previous menu.

19. EXIT –

To exit all menus.

20. (

▲/▼/◄/►

/ OK) –

Allows you to navigate the on-screen menus and

adjust the system settings to your preference. Press

▲

to

 change

picture mode during watching TV.

Press

▼

to

 change sound mode

during watching TV.

21.

 –

 To play in fast rewind mode.

22.

 –

 To play in fast forward mode.

23.

 –

 To play/pause

24. Rec

1

–

 PVR Record

25.

 –

 To restart the current chapter

26.

 –

 To advance forward to the next chapter

27.

 –

 To stop the playback

28. Rec List

1

–

 Opens the list of recordings.

29.  COLOUR BUTTONS –

 Additional teletext and OSD functions

1

 - available only with PVR function



TV buttons & Source menu

Vol+

Volume up and menu right

Vol-

Volume down and menu left

CH+

Programme/Channel up and menu up

CH-

Programme/Channel down and menu down

MENU

Displays Menu/OSD

SOURCE

Displays the input source menu

STANDBY

Standby Power On/Off



Choosing Mode Input/Source

To switch between the diff erent input/connections.

a) Using the buttons on the remote control:
1.

Press [SOURCE/ AV ] - The source menu will appear.
