The TV won’t turn on.

 • Make sure that the One Connect Box Power Cable is securely

plugged in to the One Connect Box and the wall outlet.

 • Make sure that the wall outlet is working and the remote

control sensor at the bottom of the TV is lit and glowing a
solid red.

 • Try pressing the

TV Controller

 button at the lower right rear

corner of the TV to make sure that the problem is not with the
remote control. If the TV turns on, refer to "The remote control
does not work".

The remote control does not work.

 • Check if the remote control sensor at the bottom of the TV

blinks when you press the   button on the remote control.

–

When the remote's battery is discharged, charge the
battery using the USB charging port (C-type), or turn over
the remote to expose the solar cell to light.

 • Try pointing the remote directly at the TV from 1.5-1.8 m away.
 • If your TV came with a Samsung Smart Remote (Bluetooth

Remote), make sure to pair the remote to the TV. To pair
a Samsung Smart Remote, press the   and   buttons
together for 3 seconds.

Eco Sensor and screen brightness

Eco Sensor adjusts the brightness of the TV automatically. This
feature measures the light in your room and optimises the
brightness of the TV automatically to reduce power consumption.
If you want to turn this off, go to   >

Menu

 >

Settings

>

All Settings

 >

General & Privacy

 >

Power and Energy Saving

 >

Brightness Optimisation

.

 • The eco sensor is located at the bottom of the TV. Do not

block the sensor with any object. This can decrease picture
brightness.

05  Specifications and Other

Information

Specifications

Display Resolution

3840 x 2160

Sound (Output)

43"-50": 20

W

55"-85": 40

W

Power Supply

AC100-240V~ 50/60Hz

Power Consumption

QE43LS03BAU: 110

W

QE50LS03BAU: 120

W

QE55LS03BAU: 170

W

QE65LS03BAU: 215

W

QE75LS03BAU/QE85LS03BA: 290

W

Operating Temperature

10 °C to 40 °C (50 °F to 104 °F)

Operating Humidity

10 % to 80 %, non-condensing

Storage Temperature

-20 °C to 45 °C (-4 °F to 113 °F)

Storage Humidity

5 % to 95 %, non-condensing

Notes

 • This device is a Class B digital apparatus.
 • For information about the power supply, and more information

about power consumption, refer to the information on the
label attached to the product.

–

On most models, the label is attached to the back of the TV.
(On some models, the label is inside the cover terminal.)

–

On One Connect Box models, the label is attached to the
bottom of the One Connect Box.

 • To connect a LAN cable, use a CAT 7 (*STP type) cable for the

connection. (100/10 Mbps)
* Shielded Twisted Pair

 • The images and specifications of the Quick Setup Guide may

differ from the actual product.

 • Figures and illustrations in this User Manual are provided

for reference only and may differ from the actual product
appearance. Product design and specifications may change
without notice.
