English - 18

06  Connecting the HDBase-T

HDBase-T connection of The Terrace is built-in for transmission of audio and video data. It does not support
transmission of power, Ethernet and control signals including IR and RS232.

General

• The appearance may differ depending on the product.

• Connecting parts may differ in different products.

• Data transmission is not available if HDBase-T (Rx) is connected to HDBase-T (Tx) through a hub.

• While installing the product, be sure to use the cables and TX devices certified by the HDBase-T Alliance.

• When connecting an external device via HDBase-T, for the maximum resolution, use a certified TX device

that supports 4K 30 Hz.

• This port (HDBT port on the TV) does not support ARC (eARC).

Guidelines for connection

• HDBase-T (Tx) transmits data from an external device to HDBase-T (Rx). Only 1:1 connection is available

between devices. Make sure to connect them via a LAN (CAT6 or higher quality) cable.

• HDBase-T works with unshielded twisted pair (UTP) or shielded twisted pair (STP) cables; but, to ensure

CE compliance, STP cables and STP Connectors are required. STP cable and connectors are recommended
to safeguard against unpredictable environmental electrical noise which may impact performance. It is
recommended to use an STP cable to maximise performance. Using a UTP cable or patch may decrease
performance.

• Before replacing the external device, first remove the HDBT LAN (CAT6 or higher quality) cable.
