Additional Information

DVD player

TV rear panel

Component video

cable

(not supplied)

Audio cable

 (not supplied)

L

R

R

1

L

Y

C

B

C

R

(MONO)

(MONO)

Connect

To (on the DVD player)

Y (green)

Y

C

B

 (blue)

C

B

, P

B

, C

b

 or B-Y

C

R

 (red)

C

R

, P

R

, C

r

 or R-Y

Connecting to the component video input terminal (

)

TV rear panel

Audio system

L

R

R

1

L

Y

C

B

C

R

(MONO)

(MONO)

VCR

Audio/Video

cable

(not supplied)

Connecting to the monitor output terminal (

 T

)

Notes

• If your DVD player can output interlace and progressive mode signals, select the interlace

output when connecting to

 (component video input) on your TV. Your TV can receive

either 525i/60Hz or 625i/50Hz interlace signals.

• Some DVD player terminals may be labeled differently:

• If you select “DVD” on your TV screen, the signal from the

T

 (monitor output) jacks will not

be output properly. This does not indicate a malfunction.
