TECHNICAL SPECIFICATIONS

Physical characteristics

•  Height: 205 mm
•  Width: 197 mm
•  Depth: 54 mm
•  Weight: 800 g
•  Color: gray
•  2-level adjustable foot stand: 40° or 60°
•  Wall-mountable (an adaptor is required

for compliance with standard TIA-570-C,
section 8)

•  Operating temperature: 0°C to 45°C
•  Operating humidity: 10% to 90%

Display

•  132 x 64 pixel graphic monochrome

display, 5 lines shown with backlight

Audio characteristics

•  Audio codec: G.711 (A-law and μ-law),

G.723.1, G.729AB, G.722

•  Supports VAD, CNG, AEC,  AJB
•  Volume controls
•  Mute control

Keys and navigation

Application keys

•  2 SIP account keys
•  Conference key
•  Redial key
•  Transfer key
•  Hold key

Audio keys

•  Volume control keys (+ and -)
•  Hands-free on/off key with LED
•  Mute on/off key

Indication

•  Message key with LED
•  Headset key with LED
•  Call indication LED

Navigation keys

•  Cancel key
•  4-way navigation and OK  key

Power

•  Supports 802.3AF Power over Ethernet

(POE) - Class 0*

Connectivity

•  LAN: 2 x RJ45 10/100M Ethernet ports
•  1 x 3.5 mm headset port
•  1 x RJ9 handset port
•  1 x RJ9 headset port
•  1 x USB por (DC 5V/1A output)

Management

•  Auto-provisioning via FTP/TFTP/HTTP/

HTTPS (for settings and firmware
upgrade/download)

•  Configuration via
 Browser/phone/auto-provisioning
•  Supports TR069 (China only)
•  Supports Telnet
•  Supports LLDP
•  Trace package and system log export

QoS

•  802.1p (SIP and RTP QoS)
• DSCP

Security

• 802.1x
•  Supports VPN
•  VLAN tagging (802.1q)
•  Transport Layer Security (TLS)
•  Digest authentication using MD5/MD5-sess
•  Secure configuration file via AES,

encryption

•  Admin/user 2-level configuration mode

Multi-language

•  Czech, Chinese (simplified and traditional),

Danish, Dutch, Finnish, English, Estonian,
French, German, Greek, Hebrew,
Hungarian, Icelandic, Italian, Korean,
Latvian, Lithuanian, Norwegian, Polish,
Portuguese (Brazil and Portugal), Russian,
Slovak, Slovenian, Spanish, Swedish and
Turkish.

•  Display of Unicode characters for

supported languages

Regulatory and standards safety

•  EN 60950-1
•  IEC 60950-1

EMC

•  EN 55022 Class B
•  CISPR 22 Class B
•  EN 55024
•  CISPR 24

Eco-design

•  ROHS Directive 2011/65/EU
•  WEEE Directive 2012/19/EU

Phone features

•  Support two SIP account lines, hotline
•  Support call holding, call waiting, call

forwarding and transfer (blind/busy/ask)

•  Caller ID, redial, mute, do not disturb

(DND)

•  Auto answer, conference
•  Speed-dial, voicemail
•  IP direct dial
•  Custom ring tone
•  Call records(50 logs each): dialed calls/

received calls/missed calls

Phonebook

•  Individual phonebook (300 entries)
•  Enterprise phonebook (800 entries)
•  LDAP/XML directory service

Advanced feature

•  SIP server redundancy
•  Third party call control (3PCC)

System interoperability

•  Alcatel-Lucent OmniPCX

®

 Enterprise

R11.0.1 and later

•  Alcatel-Lucent OmniPCX Office RCE R9.2

and later

•  Alcatel-Lucent OpenTouch

®

 R2.1.1 and

later

Standards references
(non-exhaustive list)

•  RFC 3261: Session Initiation Protocol (SIP)
•  RFC 2131: Dynamic Host Configuration

Protocol (DHCP)

•  RFC 2617: HTTP Authentication; Basic and

Digest Access Authentication

•  RFC 2833: RTP Payload for DTMF Digits,

Telephony Tones and Telephony Signals

•  RFC 2976: The SIP INFO Method
•  RFC 3263: Session Initiation Protocol (SIP):

Locating SIP Servers

•  RFC 3264: An Offer/Answer Model with

the Session Description Protocol

•  RFC 3515: The SIP Refer Method
•  RFC 3892: The Session Initiation Protocol

(SIP) Referred-By Mechanism

•  RFC 4028: Session Timers in the Session

Initiation Protocol (SIP)

* Maximum power for the 8001 in use without USB

charging <= 3 W
