1 609 92A 4FY | (04.07.2018)

Bosch Power Tools

18

 | English

Typically, the A-weighted sound pressure level of the power

tool is

74

 dB(A). Uncertainty K = 3 dB. The noise level when

working can exceed 80 dB(A).

Wear hearing protection

Total vibration values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 60335-2-69

: a

h

<

2.5

 m/s

2

,

K =

1

.5

 m/s

2

.

Fitting

u

Pull the plug out of the socket before cleaning or per-
forming maintenance on the vacuum cleaner, making
tool adjustments, changing accessories or putting
away the vacuum cleaner.

 This safety measure prevents

the vacuum cleaner from being started accidentally.

Fitting the vacuuming accessories (see figure A)

The vacuum hose

(16)

 is equipped with a clip system which

can be used to connect vacuuming accessories (dust extrac-
tion adapter

(14)

, curved nozzle

(17)

).

Fitting the nozzles and tubes

– Push the curved nozzle

(17)

 onto the vacuum hose

(16)

until you hear both snap fasteners

(26)

 on the vacuum

hose engage.

– Then attach the required vacuuming accessory (floor

nozzle, crevice nozzle, suction tube, etc.) firmly to the
curved nozzle

(17)

.

– To remove the accessory, press the snap fasteners

(26)

inwards and pull apart the components.

Fitting the Dust Extraction Adapter (GAS 15 PS)

– Push the dust extraction adapter

(14)

 onto the vacuum

hose

(16)

 until you hear both snap fasteners

(26)

 on the

vacuum hose engage.

– To remove the adapter, press the snap fasteners

(26)

 in-

wards and pull apart the components.

Fitting the vacuum hose

Vacuuming function (see figure B1)

– Push the vacuum hose

(16)

 into the hose connection

piece

(2)

 and turn it as far as possible in the direction of

rotation  .

Note:

 The friction generated by the dust in the vacuum hose

and accessory during extraction causes an electrostatic
charge that the user may experience as static discharge (de-
pending on environmental factors and their physiological
state).
Bosch generally recommends using an anti-static vacuum
hose (accessory) to vacuum up fine dust and dry materials.

Blowing function (see figure B2)

u

The vacuum cleaner has a blowing function. Do not
blow exhaust air out into the open air. Only use the
blowing function with a clean hose.

 Dust can be hazard-

ous to health.

– Switch on the vacuum cleaner for at least five seconds

(GAS 15: Set the on/off switch

(4)

 to "on"; GAS 15 PS:

Set the mode selector switch

(4)

 to the "vacuuming" sym-

bol) to clean the vacuum hose

(16)

 of dust deposits.

– Turn the vacuum hose

(16)

 anti-clockwise as far as pos-

sible and pull it out of the hose connection piece

(2)

.

– Insert the vacuum hose

(16)

 into the hose connection

piece

(12)

 and turn it clockwise as far as possible.

Inserting/removing the plastic bag or dust bag
(dry vacuuming) (see figures C1–C4)

For dry vacuuming, you can insert a plastic bag

(18)

 or a

dust bag (accessory) into the container

(1)

. This makes it

easier to dispose of coarse dirt.

Inserting the plastic bag

– Open the catches

(8)

 and remove the top part of the va-

cuum cleaner

(7)

.

– Insert the plastic bag

(18)

 into the container

(1)

 with the

inlet facing upwards. Secure the plastic bag under the in-
take port

(27)

 using the clips

(28)

.

– Make sure that the plastic bag

(18)

 touches all the inside

walls of the container

(1)

.

– Fold the rest of the plastic bag

(18)

 over the edge of the

container

(1)

.

– Put the top part of the vacuum cleaner

(7)

 on and close

the catches

(8)

.

Removing and sealing the plastic bag

– Open the catches

(8)

 and remove the top part of the va-

cuum cleaner

(7)

.

– Pull the edge of the full plastic bag

(18)

 backwards out of

the clips

(28)

.

– Carefully take the plastic bag

(18)

 out of the container

(1)

 without damaging it.

– When doing so, make sure that the plastic bag does not

scrape against the intake port

(27)

 or other sharp ob-

jects.

Changing/inserting the dust bag (accessory)

– Open the catches

(8)

 and remove the top part of the va-

cuum cleaner

(7)

.

– Pull the full dust bag

(18)

 backwards out of the connec-

tion flange. Close the opening in the dust bag by turning
down the top. Take the closed dust bag out of the con-
tainer

(1)

.

– Place the new dust bag over the vacuum cleaner's con-

nection flange. Make sure that the entire length of the
dust bag touches the inside wall of the container

(1)

.

– Put the top part of the vacuum cleaner

(7)

 on and close

the catches

(8)

.

Fitting the rubber lip (wet vacuuming) (see
figure D)

– Use a suitable tool to lift the brush inserts

(23)

 out of the

floor nozzle

(24)

.

– Place the rubber lips

(22)

 in the floor nozzle

(24)

.
