4

  The hidden helper may only be used with a washing machine and a dryer by the manufacturer Asko Appliances.

A

B

1

Undo the middle screw on the back side of the washing
machine.

2

Attach the anti-tip bracket

(B)

 to the upper edge of the

back of the washing machine.

  The anti-tip bracket

(B)

 is supplied in the hidden helper.

3

Attach the anti-tip bracket

(A)

 to the lower edge of the

back of the dryer.

  The anti-tip bracket

(A)

is supplied in the dryer

cardboard box.

4

Before placing the dryer onto the hidden helper, undo the
dryer legs by

fi

 ve turns from the fully retracted position,

and tighten the safety nuts all the way.

5

Lift the dryer and tilt it towards the back. Insert the back
feet of the dryer into the slots in the hidden helper and

push the dryer back towards the back of the hidden helper
until the anti-tip bracket

(A)

 locks in with the anti-tip bracket

(B)

. Anti-tip bracket position so that the bracket on the dryer

and the bracket on the washing machine are fully aligned.

6

Final installation of the hidden helper between a washing
machine and a dryer, from the back.

  To install a hidden helper between a washing machine and a dryer that are already stacked in a tower, first follow the

instructions for dismounting the tower. This means that the anti-tip bracket has to be removed first.

INSTALLING A HIDDEN HELPER BETWEEN A WASHING MACHINE
AND A DRYER
