English |

11

Action

Figure

Page

Detaching the microfiber cloth
110 mm

Cleaning microfiber cloth

L

166

Accessories

M

166

Initial Operation

Note:

 The battery is supplied partially charged. To ensure

capacity of the battery, completely charge the battery using
the battery charger before using your machine for the first
time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging procedure
does not damage the battery.
The battery is protected against deep discharging.
When the battery is discharged, the machine will stop.

Battery Charging (see figures A and C)

Note

: The micro-USB port

(20)

 for connection of the micro-

USB cable

(17)

 is in the handle.

When the battery charge is low, the charger level indicator

(4)

 flashes green.

When the charger level indicator

(4)

 flashes red, the battery

must be charged. Turn the machine off and charge the bat-
tery.
Connect the machine to the charger

(18)

 using the micro-

USB cable

(17)

 provided. Plug the battery charger

(18)

 into

the socket. The charging process begins.
During the charging procedure, the handle of the machine
warms up. This is normal.
The charger level indicator

(4)

 continuously lights up red

during the charging procedure. When the battery is fully
charged, the charger level indicator

(4) continuously lights

up green

.

Disconnect the battery charger from the mains supply when
charging process ends.
Observe the notes for disposal.

Troubleshooting

Problem

Possible Cause

Corrective Action

Machine will not switch
on

Battery discharged

Recharge battery

Battery too hot/cold

Allow to cool/warm

Restricted or no va-
cuum

Suction head blocked

Unblock suction head

Drain plug removed

Replace drain plug

Machine turns itself off Battery too hot/cold

Allow to cool/warm

Suction head blocked

Unblock suction head

Water leaks from ma-
chine

Spray applicator not mounted correctly

Mount the spray applicator correctly

Battery will not charge Battery charger not connected correctly

Check battery charger and USB cable connec-
tions

Battery too hot/cold

Allow to cool/warm

Streaking on windows Wiper blade damaged

Replace wiper blade (accessory)

Too much force applied

Apply reduced force

Too little force applied

Apply more force

Maintenance and Cleaning (see
figure K)

Always clean the product thoroughly after use.
Remove the suction head from the main body and rinse.
Whilst suction head

(2)

 is removed from the machine, fill the

dirty water tank

(7)

 via the suction head aperture to the max

line with clean, warm water. DO NOT fill the dirty water tank

(7)

 via the drain hole. Shake the machine and pour the water

out via the drain plug

(8)

.

Maintenance of the suction head

Protect the suction head against damage during storage.
Prevent the wiper blade from touching paper or cardboard,
as this could damage the wiper blades polymer coating.
Spots or lines may be visible on the polymer coating. This is
normal and does not affect the cleaning performance.

Textiles

Microfiber cloths: 67% polyester, 14% polyamide, 19%
polypropylene

Bosch Power Tools

F 016 L81 778 | (27.02.2019)
