6

 ENGLISH

Troubleshooting

Problem

Troubleshooting

When using the juice extractor for the first
time, unpleasant smell can appear.

It is normal because some time is necessary for carbon
brush lapping in motor unit.

Juice extractor does not work

1.

Make  sure  it  is  assembled  properly,  and  the  lock  is
in the locked position.

2.

Connect  any  suitable  unit  to  the  socket  in  order
to check whether voltage is available in the socket.

Juice amount has decreased rapidly

1.

The mesh filter became cluttered

–

switch the juice extractor off, remove the power plug
from the socket.

–

when electric motor stops, check the grating filter

–

clean and wash the grating filter.

Juice extractor vibrates strongly during
operation.

1.

Pulp adhesion on one side of grating filter is possible.

–

switch juice extractor off, remove the power plug from
the socket;

–

when electric motor stops, check the grating filter;

–

clean and wash the grating filter.

2.

Grating filter damage

–

examine  the  grating  filter,  in  case  of  damage
or cracks replace the grating filter.

Juice extractor operation is accompanied
by intense noise and unpleasant smell, the
unit heats up strongly, smoke appears etc.

Stop using the unit immediately, disconnect it from the
mains and apply to the authorized service center for
testing and repairing it.

DELIVERY SET

Motor unit – 1 pc.
Pusher – 1 pc.
Lid – 1 pc.
Grating filter – 1 pc.
Juice collector – 1 pc.
Pulp container – 1 pc.
Juice cup – 1 pc.
Instruction manual – 1 pc.

TECHNICAL SPECIFICATIONS

Nominal voltage: 220-240 V ~ 50 Hz
Rated current: 1.6 A
Maximal power: 900 W

RECYCLING

For environment protection do not throw out the unit
and the batteries with usual household waste after
its  service  life  expiration;  apply  to  the  specialized
center for further recycling.

The waste generated during the disposal of the unit
is subject to mandatory collection and consequent
disposal in the prescribed manner.
For further information about recycling of this prod-
uct apply to a local municipal administration, a dis-
posal  service  or  to  the  shop  where  you  purchased
this product.

The  manufacturer  preserves  the  right  to  change
design,  structure  and  specifications  not  affect-
ing general principles of the unit operation without
a  preliminary  notification  due  to  which  insignifi-
cant differences between the manual and product
may  be  observed.  If  the  user  reveals  such  differ-
ences, please report them via e-mail info@vitek.ru
for receipt of an updated manual.

Unit operating life is 3 years

Guarantee

Details regarding guarantee conditions can be ob-
tained  from  the  dealer  from  whom  the  appliance
was  purchased.  The  bill  of  sale  or  receipt  must  be
produced when making any claim under the terms
of this guarantee.
