Operating time

This machine is designed with button switches of O grading, I
grading, II grading (O for stop, I for weak grading, II for strong
grading).  For juicing, select strong grading, for operating time,
after operating for 1min, stop for 1min, then use again. After the
above operation is performed for three times, stop for 15 min, do
not operate until the motor is cooled, in this way, service life of
this machine will be prolonged, the machine will serve you more
efficiently.

1.Before using, please confirm the button switch of the main machine
   in stop state, in this way, in case assembly is not completed,
   starting the main machine can be avoided, so unnecessary
   damage for persons or property avoided.
2.Before juicing, first confirm juicing net and rotor clutched in position,

   and no hard contact between juicing net cutter and transparent
   cover. Put the transparent cover on, put the handle into the cover
   slot, then turn on the machine.
3.For using, assemble according to the diagram of "name and
   position of main components". Turn on power supply, press
   switch to let the machine run no-load for 5 sec. Put prepared
   vegetable or fruit into feed port of the juicer, press with the
   pushing bar, evenly, hard and slowly, juice of the vegetable or
   fruit can be found, original, fresh, good for health.
4. Note: when pressing food with the pushing bar, force shall be
   even or indirect, pressing force shall not be more than 1 kg, no
   too sudden force, otherwise, juicing effect will be reduced.

Juicing

3

 Diagram of name and position of main components

1

1.
   in for juicing, no cutting apart needed, easy and quick.
2.Design is fine, simple, and beautiful, with combined structure,
   easy to operate and clean.
3.High speed electric motor with overheating protection is adopted,
   high efficiency, time saving, energy saving, high service life of
   the motor.
4.Safety lock unit for switching is specially designed, in order to
   make sure safety and reliability in use.

For the juicer with large diameter, entire apple or pear can be put

 Performances

Attention before using

1.This machine is set with safety unit, when the handle does not
   fasten the cover or the cutter seat is not fastened, the motor cannot
   turn, so as to ensure safety for the user.
2.When disassembling or assembling the juicer, press the upper
   of feed port of the cover with your hand, then force the handle
   to slide in or out of cover slot.
3.When disassembling juicing net, first remove the cover and residue

   barrel, then turn the middle ring up to 30 degrees by holding juicing
   nozzle with your hand, and take up, the juicing net will automatically

   leave the rotor.

4.In order to avoid damage, before using, first check power supply
   for compliance with rated voltage .
5.Clean all parts able to disassemble (refer to the section of
   "maintenance and cleaning").
6.When assembling, please carefully read the diagram of "name
   and position of main components".
7.Please carefully read the "attentions" before using.

2

1. Pushing bar
2.Transparent cover
3. Juicing net
4. Middle ring
5. Handle

6. Residue barrel
7. Rotor
8. Main machine
9. Juicer jug

9

8

7

5

6

4

3

2

1

1.   Штовхач

2.  Прозора кришка

3.   Терка-фільтр

4.  З’єднувальна частина

5.   Ручка

6.  Контейнер для м’якоті

7.   Ротор

8.  Блок мотора

9.  Ємність для соку

ОПИС

Примітка:

 наведені в інструкції зображення призначені тільки для

довідки. Реальний пристрій, імовірно, відрізняється.
