Startup

474 910_b

15

Snow clearing tips

Clear snow right after it has fallen. If you wait

too long, the lower layer will ice up and make

clearing it more difficult.
Clear  the  snow  so  that  each  pass  overlaps

slightly.
If possible, clear the snow in the direction of

the wind.

Inspecting the machine

Perform a visual inspection each time before

operating.
Check  safety  devices,  operating  elements,

cables and all screw connections for damage

and tightness.
Replace damaged parts before operating.

Adjusting the machine to your body height

see Figure 6

1. Fold up the handle adjustment locks on both

sides.

➯

The lock catches can now be seen.

2. Adjust to the desired height.
3. Fold  down  the  handle  adjustment  locks  on

both sides.

Adjusting the throwing direction and width

CAUTION!
Risk of injury due to uncontrolled exit-

ing foreign objects!

Never aim the discharge chute in the di-

rection of people, animals, windows, au-

tomobiles or doors.

Adjusting the throwing direction

1. Move the discharge chute to the desired po-

sition by turning the crank.

Adjusting the throwing width

1. Loosen the discharge height lock to adjust the

flap higher and vice versa.

2. Tighten the lock nut again.

➯

The more steeply the flap is adjusted, the

higher and further the snow will be ejec-

ted.

Establishing the the power connection

see Figure 7

1. Insert the mains plug of the machine connec-

tion line into the switch-plug combination.

2. Secure the machine connection line with the

cable strain relief.

➯

The loop of the mains cable must be long

enough so that the cable strain relief can

glide from one side to the other.

ADVICE

The  machine  connection  must  corre-

spond to at least the standard H07RN-F

and not exceed a length of 50 m.
This  is  a  flexible,  rubber  cable  for  me-

dium  mechanical  requirements  in  dry,

moist and wet rooms as well as outdoors.

Switching on the machine

Start  the  machine  on  level  ground  only.  The

ground must be free of foreign objects. Do not lift

the machine when starting.

see Figure 8

1. Hold the start button of the switch-plug com-

bination pressed.

2. Pull the safety bar against the handle and hold

firmly.

3. Release the start button.

Switching off the machine

1. Release the safety bar.
2. Wait for the motor to come to a standstill.

Overload protection

If  the  snowblower  becomes  blocked  by  ingested

foreign  objects,  the  overload  protection  will  trig-

ger.
1. Disconnect  the  machine  from  the  mains

power.

2. Allow the motor to cool.
3. Carefully remove any foreign objects.
4. Connect  the  machine  again  to  the  mains

power supply.

After  pressing  the  overload  protection,  the  snow

blower starts working again.

MAINTENANCE AND CARE

Maintenance schedule
Before each use

Perform a visual inspection each time before

operating.
Check  safety  devices,  operating  elements,

cables and all screw connections for damage

and tightness.
Replace damaged parts before operating.

After each use

Clean  discharge  chute,  auger,  handles  and

housing.
