Sony Xperia C3 Dual (D2502) - Инструкция по эксплуатации - Страница 8

11

Wi-Fi/Bluetooth antenna area

12

Main camera lens

13

Main camera light

14

Second microphone

15

Headset jack

16

Port for charger/USB cable

17

Memory card slot cover

18

NFC™ detection area

19

Speaker

Assembly

A protective plastic sheet is attached to the screen. You should peel off this sheet before using the
touchscreen. Otherwise, the touchscreen might not function properly.

To insert the micro SIM cards

If you pull out the micro SIM card holder while the device is powered on, the device restarts

automatically.

1

Insert a fingernail into the gap between the micro SIM card slots cover and the device, then
detach the cover.

2

Using a fingernail, pull out the micro SIM card holder.

3

Place the micro SIM card on each holder, with the gold-coloured contacts on the micro SIM card
facing up.

4

Insert the micro SIM card holder back into the device.

5

Re-attach the micro SIM card slots cover.

Do not insert an incompatible SIM card into the micro SIM card slot, for example, a nano SIM

card or a non-standard card that you cut by yourself. Doing so could permanently damage

8
