Product Overview

Specifications

The SilverStone ECU05 is a PCI-E 2.0 x2 expansion card with
reversible USB 3.1 Type-C and USB 3.0 ports.  Its single USB 3.1
Type-C port is capable of fully utilizing PCI-E 2.0 x2 slot for up to
10Gbps bandwidth, which is twice the USB 3.0 performance for
offering excellent stability when multiple external USB devices are
in use simultaneously.  ECU05 also has additional two external
USB 3.0 Type-A ports and an internal 19pin USB 3.0 connector to
provide your system with five total added USB ports.  For fast
charging, one of the Type-A ports (black) meets USB Battery
Charging (BC) 1.2 standard to deliver quick and safe charging to
your mobile devices.  Finally, the ECU05 supports UASP (USB
Attached SCSI Protocol) for enhanced performance, so operating
systems with XHCI (eXtensible Host Controller Interface) can easily
detect and install ECU05 without the need for any drivers.

Includes SuperSpeed USB 3.1 external USB Type-C connector
Includes USB 3.0 internal 19pin connector and two external USB Type-A connectors
Dedicated fast charging port, compliant with USB Battery Charging (BC) 1.2
Support PCI-E 2.0 x2 with throughput up to 10Gbps
Compliant with eXtensible Host Controller Interface (XHCI) specification Revision 1.1
Compliant with USB Attached SCSI Protocol (UASP) Revision 1.0
Includes optional low profile slot cover for supporting low profile cases

Model No.

Power requirement

Form factor

USB 3.1 controller

USB 3.0 hub controller

USB ports

Transmitting speed

Operating system support

Power management

Current protection

* If your OS version is Windows 7 or earlier, please install driver (available from SilverStone website) prior to using the ECU05.
** Windows 8 or 8.1, 10 supports ECU05 automatically so you do not need to install additional driver for it.
*** User should check for XHCI function in Ubuntu/Linux or Mac OS, if computer system supports XHCI function then it can support ECU05 automatically
     without additional driver installation.

SST-ECU05

5V via SATA 15-pin power connector

Low profile - PCI-E 2.0 x2 (10Gbps)

ASMedia ASM1142

VIA Lab VL812

USB 3.1 Type-C x 1, DFP with Rp=10K

Ω

 and up to 5V 3A

USB 3.0 Type-A x 1

USB 3.0 Type-A with dedicated charging port x 1, up to 5V 2A

Internal 19pin connector x 1, for up to two USB 3.0 ports

USB 3.1 Gen 2.0 (10Gbps), USB 3.1 Gen 1.0 / USB 3.0 (5Gbps), USB 2.0 (480Mbps), USB 1.1 (12Mbps)

Windows 7 (32bit/64bit)*, 8/8.1/10 (32bit/64bit)**, Ubuntu/Linux/Mac OS***

Support USB 3.1 / USB 3.0 and USB 2.0 link power management

Support over current detection and protection

Introduction

Features

1

Expansion Cards

ECU05
