7

ZOTAC ZBOX pico

4. DisplayPort

DisplayPort supports both external (box-to-box) and internal (laptop LCD panel)

display connections.

5. USB 3.0 Type-C port

The USB 3.0 type-C port supports the SuperSpeed USB 3.0 devices. Use this port
for USB 3.0 devices for maximum performance with USB 3.0 compatible devices.

6. Reset hole

Insert a pin into the reset hole for 3 seconds to clear CMOS.

7. MicroSD memory card slot

The built-in memory card reader supports Micro SDHC/SDXC cards to expand the

storage capabilities of the ZOTAC ZBOX pico.

8. USB 3.0 ports

The  USB  3.0  port  supports  SuperSpeed  USB  3.0  devices  and  is  backwards
compatible  with  USB  2.0/1.1  devices.  Use  this  port  for  USB  3.0  devices  for
maximum performance with USB 3.0 compatible devices.

9. Power input (DC 5V, 4A)

The supplied power adapter converts AC power to DC power for use with this jack.
Power supplied through this jack supplies power to the mini-PC. To prevent damage

to the mini-PC, always use the supplied power adapter.

10. Power LED

The Power LED is always ON when power is on.

11. Power button

The power button turns the system ON and OFF.

Note 1: The power adapter may get warm or hot when in use. Do not cover the adapter and keep it away from your body.

Note 2: Due to the unique design, some connectors are placed upside down.
