Janome Memory Craft 350Е - Инструкция по эксплуатации - Страница 44

36

USB Memory (optional item)

The USB memories can be used to save stitch data and

transfer the embroidery designs between the

MC 350E and your PC.

The USB memory is available at camera shops, PC

supplies stores etc. in various sizes and forms.

Open the small door under the card slot.

Insert the USB memory into the USB socket on the MC350E.

q

  Small door

w

  USB memory (optional item)

e

  USB socket

CAUTION:

Do not turn the power off or disconnect the USB memory

while the warning sign                     or hourglass is

displayed.

Opening the designs on USB memory

Press the

USB memory

 tab.

The folder list is displayed in the window.

Press the desired

Folder selection

 key to select it.

r

  Folder selection key

The designs contained in the selected folder will be

displayed on the

Pattern selection

 keys.

Press the

Pattern selection

 key to select the desired

pattern.

MyDesign

Mode

USB Memory Stick

A   Z

Mode

USB Memory Stick

A   Z

A-001

B-002

C-003

Cancel

q

w

e

r

42

SAVING A FILE

When you press the

Save file

 key, the

Save file

 dialog

box will open.

q

Save file key

You can select a memory location from Built-in memory,

ATA PC card or USB memory.

Press one of the following keys to select the desired

location to where you wish to save the file.

w

Built-in memory key

e

ATA PC card key

r

USB memory key

The

File list

 will open if you press the Built-in memory

key, while the

Folder list

 will open if you press the PC

card key or USB memory key.

t

File list

y

Folder list

When you press the

Page

           keys, you will be able

to see the saved files in the previous and next pages.

u

Page keys

Select the desired folder and the file list of the selected

folder will open.

Press the

OK

       key to save the file and the screen will

return to the original screen.

If you do not want to save the file, press the

Cancel

key to return to the previous window.

i

OK key

o

Cancel key

NOTE:

The file name will be automatically assigned starting

from M_001 in order.

CAUTION:

Do not turn the power off or eject the card when the

warning sign                    or hourglass is showing on

the visual touch screen. Otherwise, the data stored in

the memory may be lost or damaged.

OK

Cancel

OK

Name

Save File (Built-in)

Cancel

M_001

Edit

A(F): 126x110mm

Mode

Cancel

OK

Size

A   Z

OK

Name

Save File

Cancel

M_008

M_001

M_002

M_003

M_004

M_005

M_006

M_007

q

w

e

r

t

y

i

o

Save File

Cancel

ABC

OK

u

42

SAVING A FILE

When you press the

Save file

 key, the

Save file

 dialog

box will open.

q

Save file key

You can select a memory location from Built-in memory,

ATA PC card or USB memory.

Press one of the following keys to select the desired

location to where you wish to save the file.

w

Built-in memory key

e

ATA PC card key

r

USB memory key

The

File list

 will open if you press the Built-in memory

key, while the

Folder list

 will open if you press the PC

card key or USB memory key.

t

File list

y

Folder list

When you press the

Page

           keys, you will be able

to see the saved files in the previous and next pages.

u

Page keys

Select the desired folder and the file list of the selected

folder will open.

Press the

OK

       key to save the file and the screen will

return to the original screen.

If you do not want to save the file, press the

Cancel

key to return to the previous window.

i

OK key

o

Cancel key

NOTE:

The file name will be automatically assigned starting

from M_001 in order.

CAUTION:

Do not turn the power off or eject the card when the

warning sign                    or hourglass is showing on

the visual touch screen. Otherwise, the data stored in

the memory may be lost or damaged.

OK

Cancel

OK

Name

Save File (Built-in)

Cancel

M_001

Edit

A(F): 126x110mm

Mode

Cancel

OK

Size

A   Z

OK

Name

Save File

Cancel

M_008

M_001

M_002

M_003

M_004

M_005

M_006

M_007

q

w

e

r

t

y

i

o

Save File

Cancel

ABC

OK

u

42

SAVING A FILE

When you press the

Save file

 key, the

Save file

 dialog

box will open.

q

Save file key

You can select a memory location from Built-in memory,

ATA PC card or USB memory.

Press one of the following keys to select the desired

location to where you wish to save the file.

w

Built-in memory key

e

ATA PC card key

r

USB memory key

The

File list

 will open if you press the Built-in memory

key, while the

Folder list

 will open if you press the PC

card key or USB memory key.

t

File list

y

Folder list

When you press the

Page

           keys, you will be able

to see the saved files in the previous and next pages.

u

Page keys

Select the desired folder and the file list of the selected

folder will open.

Press the

OK

       key to save the file and the screen will

return to the original screen.

If you do not want to save the file, press the

Cancel

key to return to the previous window.

i

OK key

o

Cancel key

NOTE:

The file name will be automatically assigned starting

from M_001 in order.

CAUTION:

Do not turn the power off or eject the card when the

warning sign                    or hourglass is showing on

the visual touch screen. Otherwise, the data stored in

the memory may be lost or damaged.

OK

Cancel

OK

Name

Save File (Built-in)

Cancel

M_001

Edit

A(F): 126x110mm

Mode

Cancel

OK

Size

A   Z

OK

Name

Save File

Cancel

M_008

M_001

M_002

M_003

M_004

M_005

M_006

M_007

q

w

e

r

t

y

i

o

Save File

Cancel

ABC

OK

u

42

Сохранение файла

При нажатии на клавишу сохранения файла появится

окно сохранения файла.

Клавиша сохранения файла

Теперь надо выбрать, куда сохранить файл:

во встроенную память машины, на АТА РС карту

или память USB.

Нажмите на одну из клавиш для выбора места

сохранения файла.

Клавиша встроенной памяти машины

Клавиша АТА РС карты

Клавиша USB

При нажатии на клавишу встроенной памяти машины,

откроется список файлов. Если нажать на клавиши

АТА РС карты или USB, откроется список

существующих папок.

Список файлов

Список папок

Нажав на клавиши Страницы             , можно увидеть

сохраненные файлы на предыдущей и следующей

страницах.

Клавиши страниц

Выберите желаемую папку, откроется список

сохраненных файлов.

Нажмите подтверждающую клавишу ОК

для  сохранения файла, экран вернётся

к первоначальному виду.

Если Вы не хотите сохранять файл, нажмите клавишу

отмены         и вернитесь к первоначальному окну.

Подтверждающая клавиша ОК

Клавиша отмены

ПРИМЕЧАНИЕ:

Имя файлам будет автоматически присваиваться,

начиная от М_001 и далее по порядку.

ВНИМАНИЕ:

Не отключайте питание и не вытаскивайте карту

из машины, если на экране появился

предупреждающий знак                         или курсор

в форме песочных часов. В противном случае вся

информация в памяти может исчезнуть или будет

повреждена.
