GB

O R I G I N A L   I N S T R U C T I O N S

PROPERTIES OF THE TOOL

The manual hammer drill is an ordinary electric tool, insulation Class II, which has been designed for drilling in distinct materials:

metal, wood and wooden products, plastics, concrete, walls, etc. using drills adequate for the material with a cylindrical chuck.

The hammer drill permits continuous adjustments of rotation of the spindle, changing of the direction of rotation, hammer drilling

and drilling without hammering. It may be also used to screw and remove screws, using the bits available on the market. A correct,

reliable and safe functioning of the grinder depends on its proper use, so:

Before you proceed to operate the grinder, read the manual thoroughly and keep it

.

ACCESSORIES

The package provided by the manufacturer should contain:

- hammer drill

- additional handle

- drilling depth limiting device

- chuck key

Attention! The tool is supplied without drills!

TECHNICAL PARAMETERS

Parameter

Unit of measurements

Value

Catalogue number

79005

Nominal voltage

[V]

~230

Nominal frequency

[Hz]

50

Nominal power

[W]

600

Nominal rotation

[min

-1

]

0 - 3000

Maximum hole diameter (steel)

[mm]

13

Mass

[kg]

1,75

Level of noise
 Acoustic pressure

[dB (A)]

88,0 ± 3,0

 Acoustic power

[dB (A)]

99,0 ± 3,0

Class of insulation

II

Level of vibration: drilling / hammer drilling

[m/s

2

]

2,86 ± 1,5 / 8,67 ± 1,5

Grade of protection

IP20

GENERAL SAFETY CONDITIONS

NOTE!

 Get acquainted with all the instructions below. Failure to observe them may lead to an electric shock, fire or injuries. The

notion of electric tool used in the instructions applies to all the tools which are powered with electric current, both wire tools and

wireless ones.

OBSERVE THE FOLLOWING INSTRUCTIONS

Place of work

The place of work must be properly illuminated and clean.

 Disorder and poor illumination may be a cause of accidents.

Do not work with electric tools in explosive environments, or those which contain inflammable liquids, gases or vapours.

Electric tools generate sparks, which may cause a fire in case of contact with inflammable gases or vapours.

Do not allow children and outsiders to the place of work.

 A lack of concentration may result in a loss of control over the tool.

Electric safety

The plug of the power supply cable must fit the mains socket. Do not modify the plug. Do not use any adapters whatsoever

in order to adapt the plug to the socket.

Unmodified plug which fits the socket reduces the risk of an electric shock.

Avoid contact with grounded surfaces, such as pipes, heaters and refrigerators.

 Grounding of the body increases the risk

of an electric shock.

Do not expose electric tools to precipitation or humidity.

 Water and humidity which gets into the electric tool increases the

risk of an electric shock.

Do not overload the power supply cable. Do not use the power supply cable in order to carry the tool or to connect and

disconnect the plug from the mains socket. Avoid contact of the power supply cable with heat, oils, sharp tools and

moving elements.

 Damage to the power supply cable increases the risk of an electric shock.

In case work is realised outside closed areas, it is necessary to use extension cords designed for applications outside

closed areas.

 Using a correct extension cord permits to reduce the risk of an electric shock.
