7

EN

OPERATION

WARNING:

 Always set the forward/reverse switch (3) in central position before any work

on the machine e. g. fitting and removing a battery, tool change, transport, maintenance

and storage.

To insert the battery: Place the battery into the base of the machine and slide it until it locks

with an audible click. (C)

BATTERY STATE INDICATION

The battery state during operation can be checked on the LED display (7) by pressing the

Battery state check button (11)

.

Depending on the number of illuminated LEDs the batterystate is as follows:

4 LEDs are burning - the level of charge is 100%.

2-3 LEDs are burning - the level of charge is 40-70%.

1 LED is on - charge level is 25-30%.

LED WORK AREA LIGHT

The machine is equipped with LED light (8) to illuminate the work area and improve

visibility when drilling in areas with insufficient light. To turn the LED light on press the

trigger of switch (6).

REVERSING

The extreme position of forward/reverse switch (3) to the right right (viewed from the rear)

is equivalent to anticlockwise rotation, the extreme position to the left - to

clockwise rotation. With the ON/OFF switch (3) in neutral position, switch (6)

cannot be pressed and the machine cannot be operated.

WARNING:

 Reversing can be performed only when the spindle is not rotating!

Drilling and tightening screws are performed with lever in extreme position to the left.

Removal of screws is performed with lever in extreme position to the right.

SWITCHING ON - SWITCHING OFF

Switching on: press ON/OFF switch (6).

Switching off: release ON/OFF switch (6).

This power tool is equipped with electric brake. The spindle stops rotating immediately

after releasing the switch lever.

ADJUSTING THE TORQUE

Rotate the torque adjustment collar (9) behind the chuck, to adjust the torque to each of

18 settings. The range of 18 torque settings allows better control when using the drill as a

screwdriver thus preventing over-tightening of the screws. The numbers circling the collar

are used to indicate the level of torque. The larger the number on the collar, the higher the

torque. To select any of the numbers, rotate the collar (9) until the desired number aligns

with the arrow head indicator on the housing of the machine.
