(Original instructions)

 ENGLISH

9

LED work light

When  drill  is  activated  by  pulling  the  trigger  switch  (1),  the

integrated  LED  work  light  (8)will  automatically  illuminate  the

work area.

Note:

 The work light is for lighting the immediate work surface

and is not intended to be used as a flashlight.

Bit tip holder

A bit storage slot (9) is built into the base of the tool.

 MAINTENANCE

Your  Stanley  tool  has  been  designed  to  operate  over  a  long

period  of  time  with  a  minimum  of  maintenance.  Continuous

satisfactory  operation  depends  upon  proper  tool  care  and

regular cleaning.

Your  charger  does  not  require  any  maintenance  apart  from

regular cleaning.

Warning!

 Before performing any maintenance on the tool,

remove the battery from the tool. Unplug the charger before

cleaning it.

•  Regularly  clean  the  ventilation  slots  in  your  tool  and

charger using a soft brush or dry cloth.

•  Regularly clean the motor housing using a damp cloth. Do

not use any abrasive or solvent-based cleaner.

•  Regularly  open  the  chuck  and  tap  it  to  remove  any  dust

from the interior.

PROTECTING THE ENVIRONMENT

Separate  collection.  This  product  must  not  be

disposed of with normal household waste.

Should  you  find  one  day  that  your  STANLEY  product  needs

replacement, or if it is of no further use to you, do not dispose

of  it  with  household  waste.  Make  this  product  available  for

separate collection.

STANLEY  provides  a  facility  for  the  collection  and

recycling  of  STANLEY  products  once  they  have

reached  the  end  of  their  working  life.  To  take

advantage  of  this  service  please  return  your  product  to  any

authorised repair agent who will collect them on our behalf.

You  can  check  the  location  of  your  nearest  authorised  repair

agent by contacting your local STANLEY office at the address

indicated  in  this  manual.  Alternatively,  a  list  of  authorised

STANLEY  repair  agents  and  full  details  of  our  after-sales

service  and  contacts  are  available  on  the  Internet  at:

www.2helpU.com.

Batteries

STANLEY  batteries  can  be  recharged  many  times.

At  the  end  of  their  useful  life,  discard  batteries  with

due care for our environment:

•  Run the battery down completely, then remove it from the

tool.

•  NiCd, NiMH and Li-Ion batteries are recyclable. Take them

to any authorized repair agent or a local recycling station.

Notes

STANLEY’s  policy  is  one  of  continuous  improvement  to  our

products and as such, we reserve the right to change product

specifications  without  prior  notice.  Standard  equipment  and

accessories  may  vary  by  country.  Product  specifications  may

differ by country.

Complete product range may not be available in all countries.

Contact your local STANLEY dealers for range availability

 TECHNICAL DATA

Troubleshooting

Problem

Possible caus

e

Possible solution

Unit will not start

.

Battery pack not

installed properly.

Battery pack not

charged.

Check battery pack

 installation.

Check battery pack charg-

ing requirements

Unit starts immedi-

ately upon inserting

battery

The switch has

been left in the “on”

position.

The switch must

  be

moved to “off” to prevent

the tool from immediately

starting when battery is

inserted.

Battery pack will not

charge.

Battery pack not

inserted into charger.

Charger not plugged

in.

Surrounding air

temperature too hot or

too cold.

Insert battery pack into

charger until LED lights.

Plug charger into a work-

ing outlet.

Move charger and battery

pack to a surrounding air

temperature of above 40

degrees F (45ºC) or below

105 degrees F (+40.5ºC)

Unit shuts o

ff

abruptly.

Battery pack has

reached its maximum

thermal limit.

Out of charge. (T

o

maximize the life of

the battery pack it is

designed  to shutoff

abruptly when the

charge is depleted

Allow battery pack to cool

down.

Place on charger

and allow to charge.

SBD20

Voltage

V

DC

18V

No-load speed

Min

-1

0-430/0-1700

Max. torque

Nm

55

Chuck capacity

mm

13

Max Drilling capacity

Steel/wood

mm

13/35

Weight

kg

1.5
