English
TRANSLATION OF THE ORIGINAL
6.
27.
Check that the voltage and frequency indicated on the
machine nameplate match the network. (Fig. plate).
28.
For total security guarantee gloves, overalls, safety glasses
and hearing.
29.
Skid footwear are recommended when working outdoors.
30.
Use protective caps for long hair.
31.
Do not use the machines in the presence of flammable
liquids or gases.
32.
This machine will work better and more safely at the rate for
which property is intended.
33.
Examine the cords periodically and if damaged machine
repaired by an authorized service.
34.
Browse extensible cords periodically and replace if damaged.
35.
Keep handles dry, clean and free of grease and oil.
36.
When not in use, before repair and when changing
accessories such as blades, bits and cutters, disconnect the
machine from the power supply.
37.
Before reusing a machine, it should be carefully checked to
determine that it will work properly and will be suitable for
the role to which it is intended.
38.
Examine the alignment and fixing of moving parts, breakage
of parts, mounting, and other conditions that may affect its
operation.
39.
In case of failure of the machine, a guard or other part that
is damaged should be properly repaired or replaced by a
qualified technician.
40.
Do not mix materials with a flash point below 21°C.
41.
Do not use solvents to clean tools. It could be dangerous
because of the risk of explosion.
42.
The use of any accessories or attachments other than those
recommended in this instruction manual may create a risk
of personal injury.
43.
It is essential to have adequate artificial lighting in work areas
where ambient light is insufficient.
44.
Recommended working temperatures between 0 and 40 ° C
and between 0.8 and 1.1 bar.
C. KNOW YOUR PRODUCT
Machine components:
1
Adjustable handle.
2
Mechanical speed regulator (I / II).
3
On/off switch and speed control.
4
Switch retention-off button.
5
Motor protection casing.
6
Ventilation grille.
7
Tool holder.
8
Auxiliary spanner (19 mm).
9
Spanner (22 mm).
10 Mixer
D. STARTING THE MACHINE
Items to be checked before starting the machine
Before using this machine, verify that no parts are worn out,
damaged or broken. Should you find any part that is not in proper
condition, have it repaired or replaced immediately.
The input voltage must be the same as the voltage indicated on the
machine features label. 230V machines can also be connected to
210V / 240V. 110V can also be connected to 100V / 120V.
Incorrect use may damage the tool.
Follow the instructions below:
- Only use mixing tools up to the maximum indicated
diameter.
- When using the mixing tool, make sure the revolutions
do not drop sharply or the machine stops.
Switching on and off
Switching on
- First press the switch retention off button and then press the
on switch.
Switching off
- Release the on switch to turn off the machine.
Mechanical speed regulator (fig.1)
- With the machine turned off, turn the switch to change the
speed.
- When the speed cannot be changed by turning the switch
completely, turn the mixer paddles slightly and then change
the speed.
Speed regulation (fig.2)
- Press the switch progressively to obtain the desired speed.
- The number of revolutions required depends on the material
and can be determined by testing.
- After working at a low number of revolutions, leave the
machine to operate without load at maximum revolutions for
about 3 minutes so that it cools down.
E. INSTRUCTIONS OF USE
Before any adjusting or fine tuning:
- Turn the machine off.
- Take out the plug.
- Wait until the machine has completely stopped.
MIXER: Inserting the mixer.
FAST-IN connection: (Not included)
- Insert the M14 tread of the FAST-IN adapter into the axis
toolholder connection (fig.3). Use the 19 mm spanner to fix it
tight.
- Take out the two parts that make up the mixer paddle from the
box.
- Screw the two parts together. Use the 22 mm spanner to screw
in the two parts correctly.
- Insert paddle, aligning pin with adapter’s slot (fig.4).
- Press the protector and insert pin into the slot (fig.5).
- Release the protector and check that the paddle is firmly fixed
and locked (fig.6).
M14 tread connection:
- Screw the top part of the mixer paddle into the mixer output
axis M14 (fig.7).
- Using the 22 mm spanner screw in the mixer paddle tightly,
turning it to the right. Use the 19 mm auxiliary spanner in the
output axis to secure the mixer paddle (fig.8).
REPLACING THE MIXER:
FAST-IN connection: (Not included)
- Press the protector and release the paddle.
M14 tread connection:
- Using the 22 mm spanner, unscrew the mixer paddle by turning
to the left.
- If the mixer paddle has got stuck, use a 19 mm auxiliary spanner
on the flat part of the nut.
Recommendations:
- The mixer should keep turning for a while after the machine has
been turned off.
- If the gyratory paddle touches a surface it could cause it to
rebound.
- Start the machine by pressing the on/off switch lightly to achieve
maximum speed only after the mixer paddle has been introduced
into the mixture.
- The mixer must be selected according to the product to be
stirred.
• If the product to be stirred has a low viscosity, the left
propeller mixer should be used.
• If the product to be stirred has a high viscosity the right
propeller mixer should be used.
• When stirring move the device up and down.
