ENGLISH

en

11

6.6 Change accessory

Opening the drill chuck:

Turn the drill chuck sleeve (1) clockwise.

Clamping the tool:

Open the drill chuck and insert the tool as far as

possible. Turn the drill chuck sleeve (1) in clockwise

direction until the tool is clamped securely. With a

soft tool shank, retightening may be required after a

short drilling period.

6.7 Switching power tool on/off, setting

speed

To start the machine, press the trigger (10). The

speed can be changed by pressing in the trigger.

6.8 Chuck with Quick replacement

system

(for PowerMaxx BS Quick...)

To remove:

See page 2, fig. A. Push the interlock

ring forward (a), advance and pull off the chuck (b).

To mount:

Push the interlock ring forward and move the

chuck as far as the limit stop on the drill spindle.

6.9 Chuck

(for PowerMaxx BS)

See page 2, fig. B.

To mount:

unscrew protective cap (13). Screw the

quick-clamping chuck onto the spindle thread. The

quick-clamping chuck can be tightened (

and

released again

) with an open-jawed spanner.

When working with long screw bits or bit holders, we

recommend the use of the bit clamping bush

6.31281 (see Accessories chapter).

Use only genuine Metabo accessories.
See page 4.
Only use accessories which fulfil the requirements

and specifications listed in these operating

instructions.

A

Quick-clamping chuck

.

Fitting, PowerMaxx BS: unscrew protective cap

(13). Screw the quick-clamping chuck onto the

spindle thread. The quick-clamping chuck can

be tightened (

and released again

) with an

open-jawed spanner.

B Battery pack

C Angle screwdriver attachment.

D Battery charger

E Bit  clamping  bush

F Bit  holder  with  Quick replacement system

G Bit  box

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must be carried out

by qualified electricians ONLY!

If you have Metabo electrical tools that require

repairs, please contact your Metabo service centre.

For addresses see www.metabo.com.
You can download spare parts lists from

www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.
Battery packs must not be disposed of with regular

waste. Return faulty or used battery packs to your

Metabo dealer!
Do not allow battery packs to come into contact with

water!

To protect the environment, do not dispose of

power tools or battery packs in household

waste. Observe national regulations on

separated collection and recycling of disused

machines, packaging and accessories.
Before disposal, discharge the battery pack in the

power tool. Prevent the contacts from short-

circuiting (e. g. by protecting them with adhesive

tape).

Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
U

=Voltage of battery pack

n =No-load

speed

Tightening torque for screwing:

M

A

=soft screwing application (wood)

M

B

=hard screwing application (metal)

M

C

= adjustable torque (with torque control)

Max. drill diameter:

D

 1 max

=in steel

D

 2 max

=in softwood

D

3 max

= in masonry

s

= max.  impact  rate

m

= weight (with battery pack)

G

= spindle  thread

Measured values determined in conformity with

EN 60745.

Direct current

The technical specifications quoted are subject to

tolerances (in compliance with the relevant valid

standards).

Emission values

Using these values, you can estimate the

emissions from this power tool and compare these

with the values emitted by other power tools. The

actual values may be higher or lower, depending on

the particular application and the condition of the

tool or power tool. In estimating the values, you

should also include work breaks and periods of low

use. Based on the estimated emission values,

specify protective measures for the user - for

7. Tips and Tricks

8. Accessories

9. Repairs

10. Environmental Protection

11. Technical Specifications
