Collect the particles generated at the source, avoid
deposits in the surrounding area.
Use suitable accessories for special work. In this
way, fewer particles enter the environment in an
uncontrolled manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:
- do not direct the escaping particles and the
exhaust air stream at yourself or nearby persons
or on dust deposits,
- use an extraction unit and/or air purifiers,
- ensure good ventilation of the workplace and keep
clean using a vacuum cleaner. Sweeping or
blowing stirs up dust.
- Vacuum or wash the protective clothing. Do not
blow, beat or brush.
Transport of li-ion battery packs:
The shipping of li-ion battery pack is subject to laws
related to the carriage of hazardous goods (UN
3480 and UN 3481). Inform yourself of the currently
valid specifications when shipping li-ion battery
packs. If necessary, consult your freight forwarder.
Certified packaging is available from Metabo.
Only send the battery pack if the housing is intact
and no fluid is leaking. Remove the battery pack
from the machine for sending. Prevent the contacts
from short-circuiting (e.g. by protecting them with
adhesive tape).
Illustrations are provided at the beginning of the
operating instructions.
Symbol explanation:
Movement direction
Drill bit
Slow
Fast
First gear
Second gear
Third gear
Screws
Drills, screws, threaded rods
Impact drilling
Torque
Fig. A
1 Keyless chuck
2 Additional handle
3 Slide switch (normal drilling, impact drilling) *
4 Gear switch
5 Rotation selector switch (rotation setting,
transport lock) - both sides of the machine
6 Bit depot *
7 Belt hook *
8 Battery pack release button
9 Capacity indicator button
10 Capacity and signal indicator
11 Battery pack
12 Setting wheel for
- Pulse function
- Torque control
- max. torque
13 LED light
14 Trigger switch
*equipment-specific
7.1 Battery pack, capacity and signal
indicator
Fig. B
Charge the battery pack before use.
Recharge the battery pack if performance dimin-
ishes.
The ideal storage temperature is between 10°C and
30°C.
7.2 Removing and inserting the battery pack
Fig. C
7.3 Setting the direction of rotation,
engaging the transporting safety device
(switch-on lock)
Fig. D
7.4 Select the gear
Fig. E
Do not set the gear switch (4) unless the motor
has stopped completely!
7.5 Set drill, hammer drill
Fig. A
Activate slide switch (3).
7.6 Setting torque control, maximum torque,
pulse function
Do not work for long periods with pulse
function switched on! (The motor can
overheat.)
Fig. F
Set the desired operating mode at the setting wheel
(12):
1...10 = Torque
control
= maximum
torque
= Pulse
function
7.7 Switching On/Off, setting the speed
Fig. A
Switching on, speed:
press the trigger switch (14)
. Press in the trigger switch to increase the
rotational speed.
5. Figures
6. Overview
Nm
7. Use
