ENGLISH

en

11

= Set

drilling

 by turning the sleeve (3) (max.

torque, without torque limitation)
To avoid overloading the motor, do not
jam the spindle.

= Set

impact drilling

 by turning the sleeve

(3) (max. torque, without torque limitation)
To avoid overloading the motor, do not
jam the spindle.

6.6

Change accessory

Opening the drill chuck:

Turn the drill chuck sleeve (1) clockwise.

Clamping the tool:

Open the drill chuck and insert the tool as far as
possible. Turn the drill chuck sleeve (1) in clockwise
direction until the tool is clamped securely. With a
soft tool shank, retightening may be required after a
short drilling period.

6.7

Switching power tool on/off, setting

speed

Press the trigger switch (8) to switch on the
machine. Press in the trigger to increase the
rotational speed.

6.8

Drill chuck with "Quick" change system

(for BS 18 Quick, BS 14.4 Quick)

Removal:

See page 2, fig. A. Push the interlocking

ring forward (a) and pull off the drill chuck (b).

Mounting:

Push the interlock ring forward and

move the chuck as far as the limit stop on the drill
spindle.

6.9

Drill chuck

(for BS 14.4, BS 18)

See page 2, fig. B.

Fitting:

 unscrew protective cap (15). Screw the

quick-clamping chuck onto the spindle thread. The
quick-clamping chuck can be tightened (

and

released again

) using an open-jawed spanner.

When working with long screw bits or bit holders, we
recommend the use of the bit clamping bush
6.31281 (see Accessories chapter).

Use only genuine Metabo accessories.
See page 4.
Only use accessories which fulfil the requirements
and specifications listed in these operating
instructions.

A

Quick clamping chuck

.

Clamping, BS 14.4, BS 18: unscrew protective
cap (15). Screw the quick-clamping chuck onto
the spindle thread. The quick-clamping chuck
can be tightened (

and released again

) using

an open-jawed spanner.

B Battery packs with different capacities. Only

use battery packs with voltage suitable for your
power tool.

C Angle screwdriver attachment.

D Battery  charger

E Bit clamping bush

F Bit holder with Quick replacement system

G Bit  box

For a complete range of accessories, see
www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be
carried out by qualified electricians!

Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.

You can download a list of spare parts from
www.metabo.com.

Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Battery packs may not be disposed of with regular
waste. Return faulty or used battery packs to your
Metabo dealer!
Do not allow battery packs to come into contact with
water!

Protect the environment, and do not dispose
of power tools and battery packs with house-
hold waste. Observe national regulations on

separated collection and recycling of disused
machines, packaging and accessories.
Before disposal, discharge the battery pack in the
power tool. Prevent the contacts from short-
circuiting (e. g. by protecting them with adhesive
tape).

Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
U

= Voltage of battery pack

n

= No-load speed

Tightening torque for screwing:
M

A

= soft screwing application (wood)

M

B

= hard screwing application (metal)

M

C

= adjustable torque (with torque control)

Max. drill diameter:
D

1 max

= in steel

D

2 max

= in softwood

D

3 max

= in masonry

s

= max.  impact  rate

m

= weight (with battery pack)

G

= spindle  thread

Measured values determined in conformity with
EN 60745.

Direct current

7. Tips and Tricks

8. Accessories

9. Repairs

10. Environmental Protection

11. Technical Specifications
