ENGLISH

en

10

screwdriver to firmly tighten the safety screw inside
the drill chuck (if applicable / model-specific).
Caution left-handed thread !



(see Section 8.7.)

6.1

Assembly of additional handle (2)

For safety reasons, always use the additional
handle supplied.

Open the clamping ring by turning the additional
handle (2) counter-clockwise. Push the additional
handle onto the collar of the machine. Slide the
additional handle far enough forward so that it can
be turned. At the desired angle, pull it back and
tighten firmly.

7. Use

7.1

Setting direction of rotation,



transport lock (switch-on lock)

Do not activate the rotation selector switch (7)
unless the motor has completely stopped.

See page 2.

R

= Clockwise setting

L

= Counter-clockwise setting

0

= Central position: transport lock setting

(switch-on lock)

The drill chuck must be firmly screwed onto
the spindle and the safety screw inside the drill

chuck (if applicable / model-specific) must be firmly
tightened with a screwdriver. (Caution, left-handed
thread !) If rotated counterclockwise (e.g. when
screwing) it could otherwise become loose.

7.2

Selecting a gear

Select the desired gear by turning the



thumbwheel (1).
Change speed only when the machine



is in the process of running down



(briefly switch it on and off).

1st gear (low speed, high torque)



e.g. for screwdriving, drilling

2nd gear (high speed) e.g. for drilling

7.3

Preselect speed

Use the setting wheel (5) to preselect the maximum
speed. See page 4 for recommended drilling
speeds.

7.4

Switching on/off, changing speed

Switching on, speed:

 press the trigger (9).

The speed can be changed by pressing in the
trigger.
The electronic soft start means that the machine
accelerates continuously until the preselected
speed is reached.
Release the trigger to switch off.

Continuous activation:

 While pressing on the

trigger (9), press in the locking button (8) and
then release the trigger. To switch off, press and
release the trigger (9) again.

In continuous operation, the machine
continues running if it is forced out of your

hands. Therefore, always hold the machine with
both hands using the handles provided, stand in
a safe position and concentrate.

7.5

Tool change with Plus (4)

chuck

See illustrations A, page 2.

Opening the drill chuck:

Using one hand, hold the retaining ring securely
(depending on equipment, not necessary for
BE 1300 Quick) and, using the other hand, turn the
sleeve in the direction of the arrow -1.

The ratchet sound which can possibly be heard
after opening the drill chuck is functional and is
switched off by a reverse rotation of the sleeve.

BE 751, BE 1100: If the chuck is very securely tight-
ened: Unplug. Hold the chuck using an open-end
spanner at the flats on its head, and turn the sleeve
vigorously in the direction of the arrow -1.

Clamping the tool

- Insert the tool -2- as far as possible.
- Using one hand, hold the retainer ring securely

(depending on equipment; not required for
BE 1300 Quick).

- Turn sleeve in direction -3- until the noticeable

mechanical resistance has been overcome.

-

Caution! The tool is not yet fully tightened!

Keep turning the sleeve (

it must "click" when

turning

) until it cannot be turned any further -

only

now

 is the tool

 safely

 clamped.

With a soft tool shank, retightening may be required
after a short period of operation.

7.6

Tool change with a geared chuck (3)

See illustrations B on page 2.

Opening the drill chuck:

 Open the geared chuck

with chuck key -1.

Clamping the tool:

Insert tool -2- as far as possible

and, using the chuck key, evenly secure in all 3

bores -3.

7.7

Drill chuck with "Quick" change system

(for BE 1300 Quick)

See illustration on page 2.

To remove:

Push the interlock ring forward (a),

advance and pull off the chuck (b).

To mount:

Push the interlock ring forward and

move the chuck as far as the limit stop on the drill

spindle (slightly turn the chuck if necessary).

7.8

Unscrewing chuck (when screwing with-

out chuck or when using attachments)

See illustrations Y, Z on the second last page.

Note for illus. Y, Z:

 Release by tapping lightly with a

rubber hammer, as shown, and unscrew.

Note:

 If a bit clamping bush (order no. 6.31281) is

attached, the screwdriver bit inserted in the
hexagon socket of the spindle is held in place.
