8 ENGLISH

Adjusting the fastening torque

►

Fig.5:

1.

 Action mode changing ring

2.

 Adjusting

ring

3.

 Graduation

4.

marking

5.

 Arrow

The fastening torque can be adjusted in 20 levels by turning the adjusting ring. Align the

marking with the arrow

on the tool body. Then, align the graduations with the arrow on the tool body. You can get the minimum fastening

torque at 1 and maximum torque at 20.

Before actual operation, drive a trial screw into your material or a piece of duplicate material to determine which

torque level is required for a particular application. The following shows the rough guide of the relationship between

the screw size and graduation.

Graduation

1

2

3

4

5

6

7

8

9

10 11 12 13 14 15 16 17 18 19 20

Machine screw

M4

M5

M6

Wood

screw

Soft wood

(e.g. pine)

–

ɸ

3.5 x 22

ɸ

4.1 x 38

–

Hard wood

(e.g. lauan)

–

ɸ

3.5 x 22

ɸ

4.1 x 38

–

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and unplugged before adjusting or

checking function on the tool.

Installing or removing driver bit/

drill bit

CAUTION:

 After inserting the driver bit/drill bit,

make sure that it is firmly secured. If it comes out, do

not use it.

►

Fig.6:

1.

 Tighten

2.

 Sleeve

3.

 Ring

Hold the ring and turn the sleeve counterclockwise to

open the chuck jaws. Place the driver bit/drill bit in the

chuck as far as it will go. Hold the ring firmly and turn

the sleeve clockwise to tighten the chuck.

To remove the driver bit/drill bit, hold the ring and turn

the sleeve counterclockwise.

Installing hook

Optional accessory

CAUTION:

When installing the hook, always

secure it with the screw firmly.

 If not, the hook

may come off from the tool and result in the personal

injury.

►

Fig.7:

1.

 Groove

2.

 Hook

3.

 Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool. To install

the hook, insert it into a groove in the tool housing on

either side and then secure it with a screw. To remove,

loosen the screw and then take it out.

Installing driver bit holder

Optional accessory

►

Fig.8:

1.

 Driver bit holder

2.

 Driver bit

Fit the driver bit holder into the protrusion at the tool foot

on either right or left side and secure it with a screw.

When not using the driver bit, keep it in the driver bit

holders. Driver bits 45 mm-long can be kept there.

OPERATION

CAUTION:

When the speed comes down

extremely, reduce the load or stop the tool to

avoid the tool damage.

►

Fig.9:

1.

 Vent

Hold the tool firmly with one hand on the grip.

In the case of the twisting action, hold the grip firmly

with both hands.

NOTICE:

 Do not cover vents, or it may cause over-

heating and damage to the tool.

Screwdriving operation

CAUTION:

Adjust the adjusting ring to the

proper torque level for your work.

CAUTION:

Make sure that the driver bit is

inserted straight in the screw head, or the screw

and/or driver bit may be damaged.

First, turn the action mode changing ring so that the

arrow on the tool body points to the

 marking.

Place the point of the driver bit in the screw head and

apply pressure to the tool. Start the tool slowly and then

increase the speed gradually. Release the switch trigger

as soon as the clutch cuts in.

NOTE:

 When driving wood screw, pre-drill a pilot hole

2/3 the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.
