3

ENGLISH (Original instructions)

Explanation of general view

1-1. Lock ring
2-1. Locator
3-1. Locator
4-1. Switch trigger
4-2. Lock button
5-1. Lamp

6-1. Reversing switch lever
7-1. Hook
8-1. Lock ring
8-2. Gear housing
9-1. Locator
9-2. Bit

9-3. Gear housing
10-1. Swells
10-2. Trapezoidal holes
10-3. Locator holder

SPECIFICATIONS

Model FS2200

FS2300

Self drilling screw

6 mm

6 mm

Capacities

Drywall screw

5 mm

5 mm

No load speed (min

-1

)

0 - 2,500

0 - 2,500

Overall length

287 mm

290 mm

Net weight

1.6 kg

1.6 kg

Safety class

/II

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003

ENE033-1

Intended use

The tool is intended for screw driving in wood, metal and
plastic.

ENF002-1

Power supply

The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.



For Model FS2300

ENG102-2

For European countries only

Noise

The typical A-weighted noise level determined according
to EN60745:

Sound pressure level (L

pA

) : 83 dB(A)

Sound power level (L

WA

) : 94 dB(A)

Uncertainty (K) : 3 dB(A)

Wear ear protection

ENG204-2

Vibration

The vibration total value (tri-axial vector sum)
determined according to EN60745:

Work mode: screwdriving without impact
Vibration emission (a

h

) : 2.5 m/s

2

 or less

Uncertainty (K) : 1.5 m/s

2

ENG901-1

•

The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.

•

The declared vibration emission value may also be
used in a preliminary assessment of exposure.

WARNING:

•

The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.

•

Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).


ENH101-12

EC Declaration of Conformity

We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):

Designation of Machine:

Drywall Screwdriver

Model No./ Type: FS2300
are of series production and

Conforms to the following European Directives:

98/37/EC until 28th December 2009 and then with
2006/42/EC from 29th December 2009

And are manufactured in accordance with the following
standards or standardised documents:

EN60745

The technical documentation is kept by our authorised
representative in Europe who is:

Makita International Europe Ltd,
Michigan, Drive, Tongwell,
