9 ENGLISH

Installing driver bit holder

Optional accessory

►

Fig.11:

1.

 Driver bit holder

2.

 Driver bit

Fit the driver bit holder into the protrusion at the tool foot

on either right or left side and secure it with a screw.

When not using the driver bit, keep it in the driver bit

holders. Driver bits 45 mm-long can be kept there.

OPERATION

CAUTION:

Always insert the battery cartridge all the

way until it locks in place.

 If you can see the red indicator on the

upper side of the button, it is not locked completely. Insert it fully

until the red indicator cannot be seen. If not, it may accidentally fall

out of the tool, causing injury to you or someone around you.

CAUTION:

When the speed comes down extremely,

reduce the load or stop the tool to avoid the tool damage.

Hold the tool firmly with one hand on the grip and the

other hand on the bottom of the battery cartridge to

control the twisting action.

Screwdriving operation

CAUTION:

Adjust the adjusting ring to the

proper torque level for your work.

CAUTION:

Make sure that the driver bit is

inserted straight in the screw head, or the screw

and/or driver bit may be damaged.

First, turn the action mode changing ring so that the

arrow on the tool body points to the

 marking.

Place the point of the driver bit in the screw head and apply pres-

sure to the tool. Start the tool slowly and then increase the speed

gradually. Release the switch trigger as soon as the clutch cuts in.

►

Fig.12

NOTE:

 When driving wood screw, pre-drill a pilot hole

2/3 the diameter of the screw. It makes driving easier

and prevents splitting of the workpiece.

Hammer drilling operation

CAUTION:

There is a tremendous and sudden

twisting force exerted on the tool/drill bit at the

time of hole breakthrough, when the hole becomes

clogged with chips and particles, or when striking

reinforcing rods embedded in the concrete.

First, turn the action mode changing ring so that the arrow

on the tool body points to the

 marking. The adjusting

ring can be aligned in any torque levels for this operation.

Be sure to use a tungsten-carbide tipped drill bit.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.

Do not apply more pressure when the hole becomes clogged with

chips or particles. Instead, run the tool at an idle, then remove the

drill bit partially from the hole. By repeating this several times, the

hole will be cleaned out and normal drilling may be resumed.

Blow-out bulb

Optional accessory

►

Fig.13:

1.

 Blow-out bulb

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

Drilling operation

First, turn the action mode changing ring so that the

arrow points to the

 marking. Then proceed as

follows.

Drilling in wood

When drilling in wood, the best results are obtained

with wood drills equipped with a guide screw. The guide

screw makes drilling easier by pulling the drill bit into

the workpiece.

Drilling in metal

To prevent the drill bit from slipping when starting a

hole, make an indentation with a center-punch and

hammer at the point to be drilled. Place the point of the

drill bit in the indentation and start drilling.

Use a cutting lubricant to cool the workpiece when

drilling metals. The exceptions are iron and brass which

should be drilled dry.

CAUTION:

Pressing excessively on the tool

will not speed up the drilling.

 In fact, this excessive

pressure will only serve to damage the tip of your drill

bit, decrease the tool performance and shorten the

service life of the tool.

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

CAUTION:

If the tool is operated continuously

until the battery cartridge has discharged, allow

the tool to rest for 15 minutes before proceeding

with a fresh battery.

Using the tool as a hand screwdriver

►

Fig.14

Switch off the tool.

Move the reversing switch lever to the neutral position.

Turn the action mode changing ring so that the arrow

points to the

 marking.

Turn the tool.

NOTE:

 This use is convenient for checking the

screwdriving.

NOTE:

 Do not use the tool for work requiring exces-

sive force, such as tightening bolt or removing rusted

screws.
