9 ENGLISH

Hammer drilling operation

CAUTION:

There is a tremendous and sudden

twisting force exerted on the tool/drill bit at the

time of hole breakthrough, when the hole becomes

clogged with chips and particles, or when striking

reinforcing rods embedded in the concrete.

First, turn the action mode changing ring so that the arrow

on the tool body points to the

 marking. The adjusting

ring can be aligned in any torque levels for this operation.

Be sure to use a tungsten-carbide tipped drill bit.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.

Do not apply more pressure when the hole becomes clogged with

chips or particles. Instead, run the tool at an idle, then remove the

drill bit partially from the hole. By repeating this several times, the

hole will be cleaned out and normal drilling may be resumed.

Blow-out bulb

Optional accessory

►

Fig.14:

1.

 Blow-out bulb

After drilling the hole, use the blow-out bulb to clean the

dust out of the hole.

Drilling operation

First, turn the action mode changing ring so that the arrow
points to the

 marking. Then proceed as follows.

Drilling in wood

When drilling in wood, the best results are obtained with wood

drills equipped with a guide screw. The guide screw makes

drilling easier by pulling the drill bit into the workpiece.

Drilling in metal

To prevent the drill bit from slipping when starting a hole, make an

indentation with a center-punch and hammer at the point to be drilled.

Place the point of the drill bit in the indentation and start drilling.

Use a cutting lubricant when drilling metals. The excep

-

tions are iron and brass which should be drilled dry.

CAUTION:

Pressing excessively on the tool will

not speed up the drilling.

 In fact, this excessive pressure

will only serve to damage the tip of your drill bit, decrease

the tool performance and shorten the service life of the tool.

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

CAUTION:

If the tool is operated continuously until

the battery cartridge has discharged, allow the tool to rest

for 15 minutes before proceeding with a fresh battery.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before attempting to perform inspection or

maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

OPTIONAL

ACCESSORIES

CAUTION:

These accessories or attachments

are recommended for use with your Makita tool

specified in this manual.

 The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or attachment

for its stated purpose.

If you need any assistance for more details regard-

ing these accessories, ask your local Makita Service

Center.

•

Drill bits

•

Driver bits

•

Tungsten-carbide tipped drill bit

•

Blow-out bulb

•

Driver bit holder

• Hook
•

Tool hanger

•

Makita genuine battery and charger

NOTE:

 Some items in the list may be included in the

tool package as standard accessories. They may

differ from country to country.
