8

ENGLISH

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Installing or removing driver bit/

drill bit

Optional accessory

2

3

1

1. Sleeve    2. Close    3. Open

Turn the sleeve counterclockwise to open the chuck

jaws. Place the driver bit/drill bit in the chuck as far

as it will go. Turn the sleeve clockwise to tighten the

chuck. To remove the driver bit/drill bit, turn the sleeve

counterclockwise.

Installing hook

2

1

3

1. Groove    2. Hook   3. Screw

The hook is convenient for temporarily hanging the tool.

This can be installed on either side of the tool. To install

the hook, insert it into a groove in the tool housing on

either side and then secure it with a screw. To remove,

loosen the screw and then take it out.

Installing driver bit holder

Optional accessory

2

1

1. Driver bit holder   2. Driver bit

Fit the driver bit holder into the protrusion at the tool foot

on either right or left side and secure it with a screw.

When not using the driver bit, keep it in the driver bit

holders. Driver bits 45 mm-long (1-3/4") can be kept

there.

OPERATION

CAUTION:

Always insert the battery cartridge

all the way until it locks in place.

 If you can see

the red part on the upper side of the button, it is not

locked completely. Insert it fully until the red part can-

not be seen. If not, it may accidentally fall out of the

tool, causing injury to you or someone around you.

CAUTION:

When the speed comes down

extremely, reduce the load or stop the tool to

avoid the tool damage.

Hold the tool firmly with one hand on the grip and the

other hand on the bottom of the battery cartridge to

control the twisting action.
