6

suitable for the screw, continue adjusting until you obtain
the proper depth setting.

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out any
work on the tool.

Installing or removing the bit (Fig. 8)

To remove the bit, pull the locator. Then grasp the bit with
a pair of pliers and pull the bit out of the magnetic bit
holder. Sometimes, it helps to wiggle the bit with the pliers
as you pull.

(Fig. 9)

To install the bit, push it firmly into the magnetic bit holder.
Then install the locator by pushing it firmly back.

Hook (Fig. 10)

The hook is convenient for temporarily hanging the tool.
This can be installed on either side of the tool.
To install the hook, insert it into a groove in the tool
housing on either side and then secure it with a screw. To
remove, loosen the screw and then take it out.

OPERATION

Screwdriving operation (Fig. 11)

Fit the screw on the point of the bit and place the point of
the screw on the surface of the workpiece to be fastened.
Apply pressure to the tool and start it. Withdraw the tool
as soon as the clutch cuts in. Then release the switch
trigger.

CAUTION:

• When fitting the screw onto the point of the bit, be

careful not to push in on the screw. If the screw is
pushed in, the clutch will engage and the screw will
rotate suddenly. This could damage a workpiece or
cause an injury.

• Make sure that the bit is inserted straight in the screw

head, or the screw and/or bit may be damaged.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to
perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or the

like. Discoloration, deformation or cracks may result.

To maintain product SAFETY and RELIABILITY, repairs,
carbon brush inspection and replacement, any other
maintenance or adjustment should be performed by
Makita Authorized Service Centers, always using Makita
replacement parts.

OPTIONAL ACCESSORIES

CAUTION:

• These accessories or attachments are recommended

for use with your Makita tool specified in this manual.
The use of any other accessories or attachments might

present a risk of injury to persons. Only use accessory
or attachment for its stated purpose.

If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Phillips Insert bits
• Magnetic bit holder
• Various type of Makita genuine batteries and chargers
• Plastic carrying case

NOTE:

• Some items in the list may be included in the tool

package as standard accessories. They may differ
from country to country.

Noise

ENG905-1

The typical A-weighted noise level determined according
to EN60745:

Model DFS441

Sound pressure level (L

pA

): 70 dB (A) or less

Uncertainty (K): 3 dB (A)

The noise level under working may exceed 80 dB (A).

Model DFS451

Sound pressure level (L

pA

): 71 dB (A)

Uncertainty (K): 3 dB (A)

The noise level under working may exceed 80 dB (A).

Wear ear protection.

Vibration

ENG900-1

The vibration total value (tri-axial vector sum) determined
according to EN60745:

Work mode: screwdriving without impact
Vibration emission (a

h

): 2.5 m/s

2

 or less

Uncertainty (K): 1.5 m/s

2

ENG901-1

• The declared vibration emission value has been

measured in accordance with the standard test method
and may be used for comparing one tool with another.

• The declared vibration emission value may also be

used in a preliminary assessment of exposure.

 WARNING:

• The vibration emission during actual use of the power

tool can differ from the declared emission value
depending on the ways in which the tool is used.

• Be sure to identify safety measures to protect the

operator that are based on an estimation of exposure in
the actual conditions of use (taking account of all parts
of the operating cycle such as the times when the tool
is switched off and when it is running idle in addition to
the trigger time).

For European countries only

ENH101-15

EC Declaration of Conformity
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):

Designation of Machine:
Cordless Screwdriver
Model No./ Type: DFS441, DFS451
are of series production and

Conforms to the following European Directives:

2006/42/EC

And are manufactured in accordance with the following
standards or standardised documents:

EN60745
