6

Reversing switch action (Fig. 7)

CAUTION:
• Always check the direction of rotation before opera-

tion.

• Use the reversing switch only after the tool comes

to a complete stop. Changing the direction of rota-
tion before the tool stops may damage the tool.

This tool has a reversing switch to change the direc-
tion of rotation. Move the reversing switch lever to the

i

 position for clockwise rotation or the

j

 position

for counterclockwise rotation.

Operation

Fit the screw on the point of the bit and place the
point of the screw on the surface of the workpiece to
be fastened. Apply pressure to the tool and star t it.
Withdraw the tool as soon as the clutch cuts in.

CAUTION:
• Use the proper bit for the head of the screw that you

wish to use.

• When fitting the screw onto the point of the bit, be

careful not to push in on the screw. If the screw is
pushed in, the clutch will engage and the screw will
rotate suddenly. This could damage a workpiece or
cause an injury.

• Do not continue unnecessary clutching operation.

NOTE:
• Make sure that the driver bit is inser ted straight in

the screw head, or the screw and/or bit may be
damaged.

• When driving wood screws, predrill pilot holes to

make driving easier and to prevent splitting of the
workpiece. See the chart.

MAINTENANCE

CAUTION:
Always be sure that the tool is switched off and
unplugged before carrying out any work on the tool.

To maintain product safety and reliability, repairs,
maintenance or adjustment should be carried out by
a Makita Authorized Service Center.

Nominal diameter of

wood screw (mm)

Recommended size of

pilot hole (mm)

3.1

2.0

3.5

2.2

3.8

2.5

4.5

2.9

4.8

3.1

5.1

3.3

5.5

3.6

5.8

3.8

6.2

4.0
