11
EQUIPMENT AND ACCESSORIES
1. Mixer paddle
- 2 pcs
2. Flat spanner
- 2 pcs
PREPARATION FOR OPERATION
INSTALLATION OF WORKING TOOLS
Disconnect the mixer from power supply.
Ɣ
Insert paddle shaft (
9
) into holder hole (
7
), slide it to the stop (it may be necessary to rotate the paddle
so the protrusion in the paddle shaft can be located in the holder groove).
Ɣ
Use flat spanners to tighten the holder nut (
2
) (
fig. A
).
Ɣ
Repeat above procedure to install the second mixing paddle.
DEINSTALLATION OF WORKING TOOLS
Disconnect the mixer from power supply.
Ɣ
Loosen and unscrew the holder nut (
2
).
Ɣ
Take the mixer paddle out of the holder (
7
).
Ɣ
Repeat for the other mixer paddle.
Remove mixing paddles from the mixer and clean at once when the work is finished.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the rating plate of the mixer.
The mixer is equipped with the switch lock button that protects against accidental start up.
Switching on
Ɣ
Press the switch lock button (
4
)
(
fig. B
).
Ɣ
Press the switch button (
5
).
Switching off
Ɣ
Release pressure on the switch button (
5
).
GEAR SWITCH
Range of spindles rotational speed can be changed with the use of two-position gear switch (
8
) (
fig. C
). Set
the switch in appropriate position depending on the type of mixed material.
Ɣ
Position marked with one dot is for lower rotational speed of spindles and greater torque (designed for
mixing viscous substances, such as adhesive mortars, cement, plasters etc.).
Ɣ
When the wheel is turned left to position marked with two dots, the rotational speed is greater with
lower torque (setting for mixing of liquids).
Never change the gear switch position during operation of the mixer. It may damage the mixer. Turn
the paddles slightly if the gear switch position cannot be changed.
ROTATIONAL SPEED CONTROL
Wheel for speed control of the spindles (
1
) is located on the mixer handle (
fig. D
). Adjustment range is
from 1 to 6. Rotational speed of the spindles can be changed in either gear. Turn the speed control wheel
(
1
) towards greater values to increase rotational speed, turn the wheel towards lower values to reduce
rotational speed.
PRIOR TO OPERATION
Ɣ
Ensure the power supply voltage is 230 V AC.
Ɣ
Connect the mixer to power supply network.
Ɣ
During operation, always hold the mixer firmly with both hands by two handles (
6
).
