8
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the label of the
mixer.
The mixer is equipped with the switch, which protects against
accidental starting.
Switching on
•
Press the switch lock button
(4)
located on the handle
(fig. B)
.
•
Press the switch button
(3)
.
Switching off
•
Release pressure on the switch button
(3)
.
2 GEAR SELECTOR SWITCH
Rotational speed can be changed with the use of two-position gear
switch
(2)
(fig. C)
. Depending on the work being carried out, set the
gear switch to appropriate position.
•
Position ‘1’ is for lower speed and greater torque.
•
After switching to the right, to position ‘2’, the speed is greater and
the torque is lower.
•
To restore lower speed set the switch back to the left position.
Never change the gear switch position under operation of the
mixer. It may damage the power tool. Turn the spindle slightly if
the switch position cannot be changed.
ROTATIONAL SPEED CONTROL
Wheel for rotational speed control
(7)
is located on the mixer handle
(fig. D)
. Control range is from 1 to 6, the speed can be changed
depending on the user’s needs when working on either gear.
USE OF THE MIXER
•
Ensure the power supply voltage is 230 V.
•
Connect the power tool to the power supply network.
•
During operation, always hold the mixer firmly (with both hands).
•
Electronic controller allows for slow start of the mixing (no splash)
and slow stop.
•
By turning the control wheel
(7)
you can increase or reduce
rotational speed of the spindle.
OPERATION AND MAINTENANCE
Unplug the power cord from the mains socket before commencing
any activities related to installation, adjustment, repair or
maintenance.
•
Keep the mixer clean.
•
When using the mixer always check that the ventilation holes are
not obstructed and no foreign body got between internal parts
of the power tool.
•
Any maintenance or repairs should be carried out by an authorized
service workshop.
•
During operation of the mixer, carbon brushes of the motor wear
out and they should be controlled and replaced regularly.
•
Ball bearings of the mixer are greased for the whole time of mixer
operation.
REPLACEMENT OF CARBON BRUSHES
Replace immediately worn out (shorter than 5 mm), burnt or
cracked motor carbon brushes. Always replace both brushes at
a time.
Entrust replacement of carbon brushes only to a qualified person.
Only original parts should be used.
All faults should be repaired by service workshop authorized by the
manufacturer.
TECHNICAL PARAMETERS
RATED PARAMETERS
Electric Mixer
Parameter
Value
Voltage 230
V
AC
Frequency 50
Hz
Power consumption
1600 W
Spindle rotational
speed with no load
Gear I (low)
180 ÷ 460 rpm
Gear II (high)
300 ÷ 700 rpm
Mixer shaft connection
M14, internal thread
Protection class
II
Weight
5,86 kg
Year of production
2016
NOISE LEVEL AND VIBRATION PARAMETERS
Sound pressure Lp
A
= 87,4 dB(A) K = 3 dB(A)
Sound power Lw
A
= 98,4 dB(A) K = 3 dB(A)
Weighted value of vibration acceleration a
h
= 3,02 m/s
2
K = 1,5 m/s
2
ENVIRONMENT PROTECTION
Do not dispose of electrically powered products with household wastes,
they should be utilized in proper plants. Obtain information on wastes
utilization from your seller or local authorities. Used up electric and
electronic equipment contains substances active in natural environment.
Unrecycled equipment constitutes a potential risk for environment and
human health.
* Right to changes is reserved.
