Sound pressure level
L
PA
= 97 dB(A)
Sound power level
L
WA
= 108 dB(A)
Uncertainty
K = 3 dB
CAUTION
Noise generated when working
Risk of damage to hearing
► Use ear protection.
Vibration emission level a
h
(vector sum for
three directions) and uncertainty K measured in
accordance with EN 62841:
a
h
= 24 m/s
2
K = 4 m/s
2
The specified emission levels (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary
estimates regarding vibration and noise
load during operation.
– They represent the primary applications of
the power tool.
CAUTION
The emission values may deviate from the
specified values. This is dependent on how
the tool is used and the type of workpiece
being machined.
► The actual load during the entire operating
cycle must be evaluated.
► Depending on the actual load, suitable pro
tective measures must be defined in order
to protect the operator.
3
Intended use
This cordless impact screwdriver is intended
for driving in and tightening screws up to the
specified maximum dimensions in metal, wood,
plastics and similar materials.
Self-tapping drill screws are intended for use in
metal.
It must be noted that speed is directly connec
ted to torque. This means: The lower the speed,
the lower the torque.
This power tool is intended for use with
BP Festool battery packs of the same voltage
class.
The user is liable for damage and acci
dents caused by improper and non-inten
ded use; this also includes damage and wear
caused by continuous industrial operation.
4
Technical data
Cordless impact screwdriver
TID 18
Motor voltage
18 V
Number of gears
3 + T-mode
No‑load
speed*
1st gear
1200 rpm
2nd gear
2000 rpm
3rd gear
3200 rpm
Max. torque
180 Nm
Reaction torque on the handle
10 Nm
Tool holder DIN 3126 E
1/4" (6.3 mm)
Tool holder dimension A
[5]
9.5 mm
Max. screw size for softwood
8 x 220 mm
Weight (incl. battery pack
BP 18 Li 6,2 AS) as per EPTA
procedure 01:2014
1.7 kg
* Speed values based on fully charged battery
pack.
Battery pack
BP 18
Battery voltage
18 V
5
Parts of the machine
[1-1]
Buttons for releasing the battery pack
[1-2]
Capacity display button on battery
pack
[1-3]
Capacity display
[1-4]
LED lamp
[1-5]
Electronic speed selection
[1-6]
On/off switch
[1-7]
Locking sleeve
[1-8]
Rotational direction switch and safety
lock/transport lock
[1-9]
Bit store
[1-10]
Belt clip
[1-11]
Insulated gripping surfaces (grey
shaded area)
Accessories shown or described are not always
included in the scope of delivery.
The specified illustrations appear at the begin
ning of the operating manual.
