4

EN

2.  MACHINE INFORMATION

Intended use

Your impact drill has been designed for drilling
holes in wood, metal and plastics and for hammer
drilling in brick and concrete.

Technical specifications

Mains voltage

220-240V~

Mains frequency

50/60 Hz

Power input

1100W

No-load speed (1)

0-1,200 /min

No-load speed (2)

0-3,100 /min

Impact rate (1)

0-19,200 /min

Impact rate (2)

0-49,600 /min

Max. chuck size

13 mm

Max. drill diameter

Wood

30 mm

Concrete

20 mm

Steel

13 mm

Weight

3.28 kg

Noise values

Sound pressure (L

PA

)

93.5 + 3 dB(A)

Acoustic power (L

WA

)

104.5 + 3 dB(A)

Vibration values

Drilling into metal, a

h,D

4.156  + 1.5 m/s

2

Impact drilling into concrete, a

h,ID

11.897  + 1.5 m/s

2

Vibration level

The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.

-   using the tool for different applications, or with

different or poorly maintained accessories,
may significantly increase the exposure level

-   the times when the tool is switched off or when

it is running but not actually doing the job, may
significantly reduce the exposure level

Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.

Description

The numbers in the text refer to the diagrams on
page 2.

Fig. A

1. Chuck
2. Function selection switch
3. Depth stop
4. Lock-on button

5. On/Off switch

6. Speed adjustment wheel

7. Left/right rotation switch

8. Gear selection switch
9. Side handle

Fig. B

10. Rear sleeve
11. Front sleeve

3. OPERATING

 Impact drills require very little operator
pressure. Excessive pressure on the tool
can lead to unnecessary overheating of
the motor, and burning of the driven tool.

Side handle
Fig. A

The side handle (9) can be rotated 360° around
the drill head, enabling safe and comfortable
operation for both left and right-handed users.
•   Loosen the side handle (9) by turning it

anticlockwise.

•  Rotate the side handle to the desired position.
•   Retighten the side handle in the new position by

turning it clockwise

Exchanging and removing drill bits
Fig. A - B

The machine is suitable for use of the following
drill bits:
•  Wood (HSS)
•   Metal (HSS)

•   Concrete / masonry (hard metal)
