5

EN

•   Tighten the bit by turning the front sleeve (12)

counterclockwise while simultaneously holding
the rear sleeve (11) or turning it clockwise.

Setting depth stop
Fig. A

•   Loosen the side handle (8) by turning it

counterclockwise.

•   Insert the depth stop (3) through the hole in the

side handle ring.

•   Slide the ruler to the desired depth.
•   Retighten the screw firmly by turning it

clockwise

The On/Off switch
Fig. A

•   Switch the machine on by pressing the On/Off

switch (5). When you release the On/Off switch
(5) the machine will turn off.

•   The rotation-speed can be adjusted by

pressing the On/Off switch (5) harder for
raising the rotation-speed or release pressure
for lowering the rotation-speed.

Lock-on Button
Fig. A

•   You can lock the On/Off switch (5) by pressing

the On/Off switch (5) and then pressing the
lock-on button (4).

•   To release the switch-lock; shortly press the

On/Off switch (5) again.

Adjusting of the maximum rotation speed
Fig. A

•   Switch the machine on by pressing the On/Off

switch (5).

•   Lock the On/Off switch (5) by pressing the

lock-on button (4).

Switching the direction of rotation
Fig. A

 Do not change the direction of rotation
during use.

•   Direction of rotation counter-clockwise: shift

left/right rotation switch (7) to “

”.

•   Direction of rotation clockwise: shift left/right

rotation switch (7) to “

”.

Function selection switch
Fig. A

 In order to avoid damage to the machine,
adjusting the function selection switch (2)
shall only be done when machine is not
running

•   Set the function selection switch (2) to (10) for

drilling.

•   Set the function selection switch (2) to (9) for

hammer drilling.

User tips

Always use the machine with the side handle
firmly anchored in place - you will not only work
with more comfort, you will also work with more
precision.

 Caution: drills and chisels can get very
hot.

Drilling and hammer drilling
•   For large holes, for instance in very hard

concrete, start using a smaller bit for pilot
drilling first , then drill to nominal size.

•   Hold the machine firmly with 2 hands. Be

aware the drill can jam and because of that
machine might suddenly turn (Especially when
drilling deep holes).

•   Do not apply a lot of pressure on the machine,

let the machine do the work.

4. MAINTENANCE

 Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.

Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and
dirt. Remove very persistent dirt using a soft
cloth moistened with soapsuds. Do not use any
solvents such as gasoline, alcohol, ammonia,
etc. Chemicals such as these will damage the
synthetic components.
