5

TECHNICAL DATA

Read the instruction manual completely and

carefully before using the power tool.

Protection category II power tool; double

insulated

In accordance with essential applicable safety

standards of European directives

Wear eye, ear and breath protection

Follow very carefully the instructions in this manual,

save it and keep it close at hand, ready to carry out any

inspection of parts that may be necessary.

If the tool is used with care and normal maintenance is

carried out, it will work well for a long time.

The  functions  and  use  of  the  tool  you  have

bought  shall  be  only  those  described  in  this  manual.

Any  other  use  of  the  tool  is  strictly  forbidden.

ILLUSTRATIONS

DESCRIPTION (See figures)

A  “Drilling/Impact Drilling” selector switch(Fig.1, Fig.2)

C  Drill chuck shaft gap (Fig.1, Fig.2 and Fig.3)

D  Machine neck (Fig.1, Fig.2 and Fig.3)

E   Supply cord (Fig.1 and Fig.2)

F  Thumbwheel for speed preselection (Fig.1 and Fig.2)

G  Gear selector (Fig.1 and Fig.2)

H  Auxiliary grip (Fig.1 and Fig.2)

I  Rotational direction switch (Fig.1 and Fig.2)

J  On-/off switch (Fig.1 and Fig.2)

K  Retainer button (Fig.1 and Fig.2)

L  Key type drill chuck (Fig.1 , Fig.2 and Fig.3)

M  Drill chuck key (Fig.1 , Fig.2 and Fig.3)

N  Depth gauge (Fig.1 and Fig.2)

EQUIPMENT

-  Auxiliary handle

-  Depth gauge

-  Drill chuck key

-  Operating instructions with Safety instructions

- Warranty

BRIEF DESCRIPTION

The  machine  is  intended  for  impact  drilling  in  brick,

concrete and stone as well as for drilling in wood, metal

and  plastic.  Machines  with  electronic  control  and  right/

left rotation are also suitable for screwdriving and thread-

cutting.

Additional drill characteristics

-  The rotational direction switch

I

 is used to reverse the

rotational  direction  of  the  machine.  However,  this  is  not

possible with the On/Off switch

J

 actuated.

-  Electronic  control  of  spindle  speed,  infinitely  variable

by finger pressure on the On/off switch

J

.

-  The  electronic  regulation  built-in  the  switch  trigger

F

allows  to  adjust  the  speed  suitable  for  the  material  to  be

worked.

-  For  continuous  operation  the  On-/Off  switch  can  be

locked in the “On” position by the button

K

.

BEFORE USING THIS TOOL

WARNING!

  Before  carrying  out  any  work,  check,  for

instance, using a metal detector, that there are no electric

wires or gas or water pipes under the surfaces you wish to

work on.

Make  sure  the  mains  voltage  is  correct:  it  must  be

the same as that on the specification label. Machines with

230V can also be connected to a 220V mains supply.

To  turn  the  machine  on,  press  the  ON/OFF  switch  J

and keep it pressed down.

When  the  ON/OFF  switch  is  released,  the  machine

stops.

WARNING!

 Always disconnect the plug from the

socket before doing any work on the machine.

1. Changing the Tool (fig.3).

WARNING!

  Before  any  work  on  the  machine  itself,

pull the mains plug.

WARNING!

 Wear protective gloves when changing

the tool. The drill chuck can become very hot during longer

work periods.

Open the key type drill chuck

L

 by turning until the tool

can be inserted. Insert the tool. Insert the chuck key

M

 into

the corresponding holes of the key type drill chuck

L

 and

clamp the tool uniformly.

2. Mains connection

WARNING!

 Connect only to a single-phase AC

current  supply  and  only  to  the  mains  voltage  specified

on  the  rating  plate.  Connection  to  sockets  without  earth

protection is possible as the appliance features protective

class II insulation according to European Standard EN

60745.  Radio  interference  suppression  complies  with  the

European Standard EN 60745.

3. Auxiliary handle

WARNING!

Operate your machine only with the

auxiliary handle.

-  Unscrew  the  auxiliary  handle

H

 in an anticlockwise

direction.

-  Turn the auxiliary handle

H

 to the required position.

-  Screw the auxiliary handle

H

 in place again.

4. Setting the depth gauge

Drill

DI13/820GE2 DI16/1000GE2 DI16/1050GE2

Rated voltage

V~

230

230

230

Frequency

Hz

50-60

50-60

50-60

Rated power

W

810

1010

1050

No load speed

rpm

0-830/0-2000

0-830/0-2000

0-830/0-2000

Max. steel capacity

mm

13

16

16

Chuck clamping range

mm

1.5-13

1.5-13

1-13

Weight according EPTA-Procedure 01/2003

kg

2.77

2.95

3.0
