15

en

For your safety.

Read all safety warnings and all instruc-

tions.

Failure to follow the warnings

and instructions may result in electric

shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

Do not use this power tool before you have thor-

oughly read and completely understood this

Instruction Manual and the enclosed “General

Safety Instructions” (document number

3 41 30 054 06 1). The documents mentioned should be

kept for later use and enclosed with the power tool,

should it be passed on or sold.
Please also observe the relevant national industrial safety

regulations.

Intended use of the power tool:

hand-held drill for drilling without water supply in metal,

wood, plastic and ceramics in weather-protected envi-

ronments using the application tools and accessories rec-

ommended by FEIN;
– Drills with right and left-hand rotation: Also intended

for thread cutting (tapping).

– ASq672-1: additionally also for expanding pipes (by

rolling) or for driving e. g., rollers, spindles, gate valves

or slider controls.

Special safety instructions.

Use auxiliary handles provided with the machine.

 Loss of

control can lead to injury.

Hold power tool by insulated gripping surfaces, when per-

forming an operation where the cutting accessory may con-

tact hidden wiring or its own cord.

 Cutting accessory

contacting a “live” wire will make exposed metal parts of

the power tool ‘“live” and shock the operator.

Secure the workpiece firmly.

 A work piece that is gripped

tightly in a clamping device or vice, is more secure than if

held by hand.

Hold the power tool firmly.

 High reaction torque can

briefly occur.

Do not rivet or screw any name-plates or signs onto the

power tool.

If the insulation is damaged, protection against

an electric shock will be ineffective. Adhesive labels are

recommended.

Do not use accessories which are not specifically designed

and recommended by the tool manufacturer.

 Just because

the accessory can be attached to your power tool, it does

not assure safe operation.

Clean the ventilation openings on the power tool at regular

intervals using non-metal tools.

 The blower of the motor

draws dust into the housing. An excessive accumulation

of metallic dust can cause an electrical hazard.

Beware of any concealed electric cables, gas or water con-

duits;

 check the working area with a metal detector, for

example, before commencing work.

Before putting into operation, check the mains connection

and the mains plug for damage.

This machine is also intended to be powered by a.c. gen-

erators with sufficient power output that correspond

with ISO 8528, design class G2. Compliance with this

Standard in particular is not given when the so-called dis-

tortion factor exceeds 10%. When in doubt, inform

yourself about the generator in use.

Hand/arm vibrations

The vibration emission level given in this information

sheet has been measured in accordance with a standard-

ised test given in EN 60745 and may be used to compare

one tool with another. It may be used for a preliminary

assessment of exposure.

Character

Unit of measure,

international

Unit of measure,

national

Explanation

n

0

/min

rpm

No-load speed

n

1

/min

rpm

Speed, full load

V

V

Rated voltage

f

Hz

Hz

Frequency

P

1

W

W

Power input

P

2

W

W

Output

M…

mm

mm

Size of metric thread

L

wA

dB

dB

Sound power level

L

pA

dB

dB

Sound pressure level

L

pCpeak

dB

dB

Peak sound pressure level

K…

Uncertainty

m/s

2

m/s

2

Vibration emission value (triax vector sum) deter-

mined according to EN 60745

h. D

m/s

2

m/s

2

Mean vibrational value for drilling in metal

m, s, kg, A, mm, V,

W, Hz, N, °C, dB,

min, m/s

2

m, s, kg, A, mm, V,

W, Hz, N, °C, dB,

min, m/s

2

Basic and derived units of measure from the inter-

national system of units

SI

.

WARNING
