16

en

The declared vibration emission level represents the

main applications of the tool. However if the tool is used

for different applications, with different accessories or

poorly maintained, the vibration emission may differ.

This may significantly increase the exposure level over

the total working period.

An estimation of the level of exposure to vibration

should also take into account the times when the tool is

switched off or when it is running but not actually doing

the job. This may significantly reduce the exposure level

over the total working period.

Identify additional safety measures to protect the opera-

tor from the effects of vibration such as: maintain the tool

and the accessories, keep the hands warm, organisation

of work patterns.

Handling hazardous dusts

For work procedures with this power tool where mate-

rial is removed, dusts develop that can be hazardous to

one’s health.

Contact with or inhaling some dust types, e. g. asbestos

and asbestos-containing materials, lead-containing coat-

ings, metal, some wood types, minerals, silicate particles

from materials containing stone, paint solvents, wood

preservatives, and antifouling paints for vessels, can trig-

ger allergic reactions to the operator or bystanders and/

or lead to respiratory infections, cancer, birth defects or

other reproductive harm. The risk from inhaling dusts

depends on the exposition. Use dust extraction matched

appropriately for the developing dust, as well as personal

protective equipment and provide for good ventilation of

the workplace. Leave the processing of asbestos-contain-

ing materials to specialists.

Wood and light-metal dust, hot mixtures of sanding dust

and chemical materials can self-ignite under unfavourable

conditions or cause an explosion. Avoid sparking in the

direction of the dust collector as well as overheating of

the power tool and the materials being sanded, empty

the dust collector/container in time, observe the material

manufacturer’s working instructions, as well as the rele-

vant regulations in your country for the materials being

worked.

Operating instructions.

Before assembling, degrease the drive spindle and the

internal taper of the drill chuck.
Change the gear setting or the rotation direction only

after the motor has come to a complete stop.
For stationary use in a drill stand, remove the switched

off power tool from the drill stand every 50 operating

hours while at normal running temperature. Then, turn

the machine around by 180° and run it for approx.

1 minute to achieve uniform lubrication.

Repair and customer service.

When working metal under extreme operat-

ing conditions, it is possible for conductive

dust to settle in the interior of the power

tool. The total insulation of the power tool can be

impaired. Blow out the interior of the power tool via the

ventilation slots frequently with dry and oil-free com-

pressed air, and connect a residual current device (RCD)

on the line side.

ASq672-1: For continuous use, apply grease via the

corresponding lubrication nipple to the mechanical

gearbox on a weekly basis.

If the supply cord of this power tool is damaged it must

be replaced by a specially prepared cord available

through the FEIN customer service centre.

If required, you can change the following parts yourself:

Drill chuck, application tools, Auxiliary handle

Warranty and liability.

The warranty for the product is valid in accordance with

the legal regulations in the country where it is marketed.

In addition, FEIN also provides a guarantee in accordance

with the FEIN manufacturer’s warranty declaration.
The delivery scope of your power tool may include only

a part of the accessories described or shown in this

instruction manual.

Declaration of conformity.

FEIN declares itself solely responsible for this product

conforming with the relevant provisions given on the last

page of this Instruction Manual.

Environmental protection, disposal.

Packaging, worn out power tools and accessories should

be sorted for environment-friendly recycling.
