English |

13

(10)

Handle (insulated gripping surface)

(11)

Universal bit holder

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Cordless drill/driver

UniversalImpact 18

Article number

3 603 JC8 1..

Rated voltage

V=

18

No-load speed

– 1st gear

min

-1

0–400

– 2nd gear

min

-1

0–1350

Max. torque, hard/soft
screwdriving application ac-
cording to ISO 5393

Nm

30/18

Max. drilling diameter (first/second gear)

– Steel

mm

10

– Wood

mm

30

Max. screw diameter

mm

8

Tool holder

mm

10

Max. impact drilling diameter

mm

6

Weight according to
EPTA-Procedure 01:2014

kg

1.3–1.6

A)

Permitted ambient temperature

– during charging

°C

0... +35

– during operation

B)

°C

-15... +50

– during storage

°C

-15... +50

Recommended batteries

PBA 18V...W-.

Recommended chargers

AL 18...

A) Depends on battery in use
B) Limited performance at temperatures <0 °C

Noise/Vibration Information

Noise emission values determined according to

EN 62841-2-1

.

Typically, the A-weighted noise level of the power tool is:
Sound pressure level

86

 dB(A); sound power level

97

 dB(A). Uncertainty K=

5

 dB.

Wear hearing protection

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841

:

Drilling into metal: a

h

<

2.5

 m/s

2

, K=

1.5

 m/s

2

Impact drilling into concrete: a

h

=

18

 m/s

2

, K=

3

 m/s

2

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the

power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.

Assembly

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

Charging the Battery

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your power tool.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.

u

Do not continue to press the On/Off switch after the
power tool has automatically switched off.

 The battery

can be damaged.

Removing the battery

To remove the battery , press the battery release button and
pull the battery to the rear and out of the power tool.

Do not

use force to do this.

Changing the tool (see figure A)
